VALUE Adapter, DP M - DVI F

VALUE

12.99.3157

Jauns

DisplayPort to DVI adapter for connecting a graphics card with DP to a monitor with DVI connection - with a resolution of up to 1920x1080 / 1920x1200 @60Hz!

  • If you want to connect a graphic card with DisplayPort Female to a monitor by using a DVI cable, you need this DisplayPort to DVI adapter
  • Connectors: DisplayPort Male, DVI Female
  • Max. resolution: 1920x1080 @60Hz

  • Remark: The DisplayPort-DVI adapter is only working in one direction: the DisplayPort plug has to be connected to the source device (e.g. graphic card)



ManufacturerVALUE
Product groupAdapters, Terminators, Converters
Product typeDisplayPort-DVI Adapter
Length0.15 m
Max. resolution1920 x 1080 / 1920 x 1200 @60Hz (2K, Full HD)
Side 1 connection (PC)DisplayPort Stecker
Side 2 connection (Peripherals)DVI F
Side 1 Connector TypeDisplayPort
Side 1 Connector GenderMale
Side 2 Connector TypeDVI-D 24+1, Dual-Link
Side 2 Connector GenderFemale
Active / PassivePassive
Area of applicationExternal
Dimensions (HxWxD)14 x 44 x 44 mm
Current catalog editionC20-03.33

VGA / SVGA
