Eaton USV EL1200USBDIN 1200VA 750W USB

EATON CORPORATION

EL1200USBDIN

Jauns

The Eaton Ellipse ECO is a slim-line power protection with built-in high performance surge-protection device (compliant with IEC 61643-1 standard). With an efficient electrical design and the EcoControl function (USB models) the Eaton Ellipse ECO helps you make energy savings of up to 25 per cent compared to previous-generation UPSs.

UPS topologyStandby (Offline)
Output power capacity1.2 kVA
Output power750 W
Input operation voltage (min)161 V
Input operation voltage (max)284 V
Input frequency50/60 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Emergency Power Off (EPO)N
Surge protectionY
Surge protection featuresFax, Modem, Network, Telephone
Audible alarm(s)Y
Audible alarm modesBattery replacement
AC outlet typesType F
Power plugC14 coupler
AC outlets quantity8 AC outlet(s)
USB 2.0 ports quantity1
Modem (RJ-11) ports1
Ethernet LAN (RJ-45) ports1
Battery technologySealed Lead Acid (VRLA)
Typical backup time at half load10 min
Hot-swap batteryN
Automatic battery testY
Cold startY
Form factorTower
Product colourBlack
Rack capacity2U
LED indicatorsBattery replacement
SafetyIEC 62040-1, IEC 60950-1, IEC 62040-2, CB Report, CE mark, IEC 61643-1
Width81 mm
Depth312 mm
Height305 mm
Weight6.7 kg
Bundled softwareEaton Intelligent Power
Harmonized System (HS) code85078000
Input connection typeSchuko
Mac compatibilityY
Nominal output voltage220-240 V
Nominal input voltage230 V
Compatible operating systemsWindows 7/Vista/XP\r\nMac OS X\r\nLinux
Overload protectionY

UPS lineinteractive
