The Intellinet Network Solutions 10GBase-T to 10GBase-R Media Converter offers the network designer a device for migration from copper-based Ethernet to Fibre Ethernet. Now, migration or expansion of existing networks can be achieved with minimum cost and complexity. The converter is completely transparent to the network, so the network performs exactly the way it did before, only now it can support both copper and Fibre media. And with a super-fast 10 Gbps connection, network speed stays constant for high-bandwidth data transfers._x000D_ _x000D_ Expand The size of an existing network._x000D_ _x000D_ The 10GBase-T to 10GBase-R Media Converter Provides fibre connectivity to Ethernet segments, allowing for even greater networking expansion between extended workgroups. It also provides building-to-building connectivity without the need for the cost and disruption associated with the installation of additional routers._x000D_ _x000D_ Enhance the distance between networking devices._x000D_ _x000D_ Connecting the converter to fibre segments further extends distances between network nodes, offering increased spatial and distance options for networks where none existed before._x000D_ _x000D_ Cabling Flexibility_x000D_ _x000D_ Network managers can install fibre cabling anywhere within a network without changing the arrangement of their copper-based Ethernet. The compact size of the converter allows it to be easily deployed in any narrow desktop location or to be used in a wall-mount installation. Several converters can be simultaneously installed into a 19"; rackmountable chassis, providing much-needed flexibility for networks.
|
| Maximum data transfer rate | 10000 Mbit/s | | Networking standards | IEEE 802.3u | | Ethernet interface type | 10 Gigabit Ethernet | | Ethernet LAN data rates | 10,100,1000,1200,2500,5000,10000 Mbit/s | | Auto-negotiation | Y | | Duplex system | Full, Half | | Fiber optic connector | SFP+ | | Connectivity technology | Wired | | Ethernet LAN (RJ-45) ports | 1 | | Fiber ports quantity | 1 | | Maximum transfer distance | 100 m | | Internal | N | | LED indicators | Activity, Link | | Product colour | Black | | Housing material | Metal | | Input voltage | 12 V | | Input current | 0.5 A | | Power consumption (max) | 5 W | | External power adapter | Y | | Width | 70 mm | | Depth | 95 mm | | Height | 25 mm | | Weight | 200 g | | Operating temperature (T-T) | 0 - 55 °C | | Storage temperature (T-T) | -10 - 70 °C | | Operating relative humidity (H-H) | 5 - 80% | | Manual | Y | | Harmonized System (HS) code | 85176990 |
|
