INTELLINET PoE Injektor 1-Port 48V DC IEEE 802.3af sw retail

Kods 524179

Condition: Jauns

Vairāk informācijas

Reduce costs by using existing Cat5 cable to provide both power and data. The INTELLINET NETWORK SOLUTIONS Power over Ethernet Injector allows you to connect your IEEE 802.3af-compliant products to a non-PoE LAN switch port. The injector can be used to connect a wireless access point, IP phone, network camera or any IEEE 802.3af powered device (PD) to a switch. Reduce Wiring Costs No need to run AC power lines for your wireless access point, network camera or IP phone. Simply connect the PoE Injector to the LAN switch port, and use the existing Cat5 cabling to deliver DC power as well as transfer data. Preserve Existing Investments Does your existing LAN switch not support the new IEEE 802.3af PoE standard? Well, don't let that stop you from realising the benefits of delivering DC power over the existing Cat5 Ethernet cabling. Use the Model 503389 PoE Injector until you are able to upgrade your LAN switch to a model that supports the IEEE 802.3af PoE standard. Protect Your Equipment Now that you are running DC power to your networked equipment through the Cat5 cabling, you need to be sure that the products are protected from power problems. The PoE Injector was designed to protect equipment from short circuits (short GRND), current overloads (over 450 mA) and high voltages (voltage exceeding 52 V).

Ethernet interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s
Power over Ethernet (PoE)	Y
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Cable types supported	Cat5
Product colour	Black
LED indicators	N
Safety	SCP
Power protection features	Over voltage, Overload, Short circuit
Certification	FCC Class B, Part 15, CE 89/336/EEC, UKCA, NDAA
Ethernet LAN (RJ-45) ports	2
Power over Ethernet (PoE) voltage	52 V
Power requirements	15.4 W
AC adapter frequency	50/60 Hz
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Input current	0.45 A
AC adapter output voltage	48 V
Output current	0.35 A
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90%
Storage temperature (T-T)	-20 - 85 °C
Size (imperial)	5.08 cm (2")
Width	50 mm
Depth	120 mm
Height	35 mm
Weight	140 g
Number of products included	1 pc(s)
Manual	Y
Harmonized System (HS) code	85044095
