Level One LevelOne Netzwerkadapter GNC-0113 PCI Ethernet 1x RJ45 grün

LEVEL ONE

GNC-0113

Jauns

The LevelOne GNC-0113 2.5-Gigabit PCIe network card facilitates high-speed connectivity within network, with PCI Express (v3.1 compliant) supporting speeds of up to 2.5 Gbps. Wake-on-LAN functionality allows remote start-up. GNC-0113 Supports IEEE 802.1P Layer 2 Priority Queuing for improving traffic flow. IEEE 802.1Q VLAN allows network segmentation, further enhancing performance and security.

Connectivity technologyWired
Host interfacePCI Express
InterfaceEthernet
Ethernet LAN (RJ-45) ports1
PCI version3.1
Maximum data transfer rate5000 Mbit/s
Networking standardsIEEE 1588, IEEE 802.1as, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u
Ethernet LAN
Ethernet interface type2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates10,100,1000,2500 Mbit/s
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T, 2500BASE-T
Wake-on-LAN ready
Jumbo frames support
Jumbo frames9500
Supported network protocolsIPv4, IPv6
Internal
Component forPC/Server
Product colourGreen
Country of originChina
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%
Sustainability compliance
Sustainability certificatesCE, Federal Communications Commission (FCC), RoHS
Width72 mm
Depth55 mm
Height20 mm
Weight40 g
Package width183 mm
Package depth152 mm
Package height30 mm
Package weight150 g
Mounting brackets included
Resource CD
Quick installation guide
Harmonized System (HS) code8517620090
Pallet gross width120 cm
Pallet gross length80 cm
Pallet gross height189.4 cm
Master (outer) cases per pallet19 pc(s)
Master (outer) case width490 mm
Master (outer) case length340 mm
Master (outer) case height350 mm
Master (outer) case gross weight10 kg
Products per master (outer) case60 pc(s)
Buffer size40 KB
