• Ideal for KVM extension, applications of AV extension, interactive digital signage␍• No software or driver required␍• Plug & play␍• Extend transmission up to 70m at Full HD 1080p, and 40m at 4K/2K @30Hz␍• HDTV compatible (720p, 1080i, 1080p, 4K/2K)␍• HDCP & EDID compliant pass-through␍• Support CEC and auto-equalization ␍• Supports High Definition Audio (HD) Surround Sound Supports; triple Audio Line Outs (S/PDIF on TOSLINK / S/PDIF on RCA / Stereo on Earphone Jack)␍• Bi-directional IR extension␍• Supports HDMI local loopback in Transmitter (TX) box␍• Bracket mountable␍• Power supply unit included␍␍
|
| Manufacturer | ROLINE | | Product group | Switch boxes KVM | | Product type | KVM-Extender, HDMI | | Scope of delivery | Transceiver unit, receiver unit, 2x power supply, manual | | PC/Switch: monitor connection | 1x HDMI | | Remote Console: Monitor connection | 1x HDMI | | Network connection | RJ45 | | Max. resolution (nominal) | 3840 x 2160 | | Dimensions (HxWxD) | 31 x 131 x 150 mm | | Weight | 775 g | | Power supply output | DC 5V; 2A | | Gross weight | 1,335 | | Current catalog edition | C17-03.09 |
|
