Level One LevelOne HDMI HVE-9214PT über Cat5 Transmitter 4 Channel POE

LEVEL ONE

HVE-9214PT

Jauns

The HVE-92 series is a HDMI extension solution supports HDBaseT technology which transmits HDMI signal and multi-channel audio at resolution Ultra HD 4K x 2K (3840 x 2160 @ 30Hz) and 1080p Full HD up to 100m via Cat5e or Cat6 cable.The series of products are embedded with EDID priority management of HDMI outputs supports EDID Hotplug refreshing function. These products also provide Bi-Directional RS-232 and IR to control the connected devices from either source or display location.All the features are made to simplify installation and reduce costs, but at the same time providing exceptional video and audio quality. The HVE-92 series is the perfect solution for Digital Signage, trade shows, home theater installations, medical facilities, and other public exhibitions.Key Features - IEEE 802.3af PoE compliant to simplify deployment and installation - Simple Plug and Play installation - Built-in EDID Hot Plug Detection (HPD) - HDMI outputs with EDID management - Transmission distance of up to 100m for HDMI(4k2k), IR and RS-232 - Bi-Directional RS-232 pass through & IR Control - Supports video resolutions up to 3840 x 2160 (4K x 2K) @ 30Hz - HDMI and HDCP complaint - Supports Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, LPCM 7.1 audio - Supports 3D, CEC & Lip Sync pass-through - Screw-in power socket for added safety

TypeAV transmitter
Maximum resolution3840 x 2160 pixels
Cable types supportedCat5e, Cat6
Maximum transfer distance100 m
Audio systemMultichannel
Audio output channels7.1 channels
LED indicatorsLink, PoE, Power
Supported video modes1080p
Bandwidth10.2 Gbit/s
HDCPY
MaterialMetal
Colour depth36 bit
3DY
HDCP & EDID bypassY
Consumer Electronics Control (CEC) supportY
Carrier frequency38 kHz
Baud rate115.2 Kbit/s
Plug and PlayY
Networking standardsIEEE 802.3af
RJ-45 output ports4
HDMI in1
Number of HDMI outputs1
RS-232 input ports1
3.5 mm (1/8-inch) inY
3.5 mm (1/8-inch) outY
DC-in jackY
Operating voltage12 V
Power consumption (transmitter) (max)5000 mA
Current6.6 A
Power over Ethernet (PoE)Y
Width300 mm
Depth160 mm
Height44 mm
Weight380 g
Transmitter dimensions (WxDxH)300 x 160 x 44 mm
Transmitter weight1.27 kg
Package dimensions (WxDxH)280 x 160 x 120 mm
Package width280 mm
Package depth160 mm
Package height120 mm
Package weight2.25 kg
Package typeBox
AC adapter includedY
Cables includedAC
ManualY
Remote control includedY
Country of originTaiwan
