Level One LevelOne SFP+ Transceiver 10G Kupfer zu Glasfaser 30m RJ45

LEVEL ONE

SFP-6601

Jauns

The LevelOne SFP-6601 is the latest generation of 10Gbps copper SFP+ transceivers. It provides a powerful duplex data link for bidirectional communication over copper Ethernet cables. The SFP-6601 transmits data from 10GBase-T copper to SFP fiber optic interfaces at up to 10 Gbps and a maximum cable length of up to 30 meters over Category 6a, 7 and 8 twisted pair cables. Ideal for servers and storage systems requiring high bandwidths. The SFP-6601 offers system developers and planners a high degree of flexibility.

SFP transceiver typeCopper
Maximum data transfer rate10000 Mbit/s
Interface typeSFP+
Maximum transfer distance100 m
Ethernet interface type2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet
Networking standardsIEEE 802.3, IEEE 802.3an, IEEE 802.3az
Copper ethernet cabling technology10GBASE-T, 1000BASE-T
Product colourSilver
Hot-swapY
CertificationCE
Maximum voltage3.3 V
Maximum current0.7 A
Power consumption (typical)1.05 W
Operating temperature (T-T)0 - 60 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Width67 mm
Depth8.5 mm
Height13.4 mm
Weight20 g
User guideY
Sustainability certificatesRoHS
Harmonized System (HS) code85369010
