Digitus 10Gbps Dual Port Ethernet Server adapter

Kods DN-10163

Condition: Jauns

Vairāk informācijas

10Gbps Dual Port Ethernet Server adapter PCIe X8, Intel X540 BT2

10Gbps Dual Port Ethernet Server adapter, incl. low Profile brackets

Low cost, low power, 10 Gigabit Ethernet (10GbE) performance for the entire data center
Standard CAT-6a cabling with RJ45 connectors
Backward compatibility with existing 1000Base-T networks simplifies the transition to 10GbE
Flexible I/O virtualization for port partitioning and quality of service (QoS) of up to 64 virtual ports
Unified networking delivering LAN, iSCSI, and FCoE in one low cost CNA
Industry first dual-port 10GBase-T adapter with single-chip solution with integrated MAC + PHY
Reliable and proven 10 Gigabit Ethernet technology from Intel corporation
Network / Transport Protocol: TCP/IP, UDP/IP, IPSec, iSCS

DN-10163 is PCI-e 10Gbps Dual RJ45 Port Ethernet Network Card , based on INTEL X540 Chipset, which is used by many OEMs as a single chip solution for LAN on Motherboard (LOM) to deliver 10 Gigabit Ethernet(10 GbE) on the latest server platforms.
10GBASE-T converged network adapter simplifies migration to 10 GbE, provides iSCSI, FCoE, Virtualization, and Flexible Port Partitioning."

Standard CAT-6a cabling with RJ45 connectors
Backward compatibility with existing 1000Base-T networks simplifies the transition to 10GbE
Flexible I/O virtualization for port partitioning and quality of service (QoS) of up to 64 virtual ports
Unified networking delivering LAN, iSCSI, and FCoE in one low cost CNA
Industry first dual-port 10GBase-T adapter with single-chip solution with integrated MAC + PHY
Reliable and proven 10 Gigabit Ethernet technology from Intel corporation
Network / Transport Protocol: TCP/IP, UDP/IP, IPSec, iSCS
Features Link Aggregation Control Protocol (LACP)
Compliant Standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP)
Dual Port 10GbE adapters
PCI Express v2.1,5.0 GT/s, x8 lanes
PXE, iSCSI, FCoE boot
Compatibility with Existing 1000BASE-T Networks Simplifies the Transition to 10GbE
Controller: Intel X540 BT2
"Network Standard Physical Layer Interfaces: Cat-6A 10G up to 100m, Cat-6 10G up to 55m
Cat-5E/Cat-6/Cat-6A 1G/100M up to 100m"
Jumbo Frame Support: Up to 9.5 KB
Network Virtualization: VMDq, PCI-SIG SR-IOV, Intel VT-c
IEEE 802.3an/ab and 10G Ethernet Specification Compliance
Low Profile and Full-Height bracket
System Requirements: FreeBSD, Linux , VMWare ESXi, Win7/ Win-server2012/ Win-server2008/ Win8/Win8.1/Win-server2016/win10 / 11
System Requirements: One available PCI Express x1 slot

Package content:
1 x DN-10163 PCIe Network card
1 x Low profile bracket
1 x Users Manual
1 x Driver CD

Platums(cm)	21.8
Grums(cm)	3
Augstums(cm)	15.5
Svars(kg)	0.28
Tilpums(cm3)	1013.7
Izcelsmes valsts	CN
