| Cabling technology | 10Base-T, 100BASE-T, 100Base-FX |
| LED indicators | LAN |
| Certification | FCC Class B, VCCI Class B, CE Class B |
| Power consumption (typical) | 7.2 W |
| Weight | 300 g |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Package width | 208 mm |
| Package depth | 274 mm |
| Package height | 68 mm |
| Package weight | 769 g |
| Shipping (inner) case length | 37 cm |
| Shipping (inner) case width | 29.1 cm |
| Shipping (inner) case height | 45.2 cm |
| Shipping (inner) case net weight | 7.69 kg |
| Products per shipping (inner) case | 10 pc(s) |
| Pallet gross weight (air) | 391 kg |
| Master (outer) cases per pallet (air) | 44 pc(s) |
| Products per pallet (air) | 440 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 194.3 cm |
| Pallet gross weight (sea) | 391 kg |
| Master (outer) cases per pallet (sea) | 44 pc(s) |
| Products per pallet (sea) | 440 pc(s) |
| Pallet height (sea) | 194.3 cm |
| Shipping (inner) case gross weight | 8.39 kg |
| Harmonized System (HS) code | 85176990 |
| Dimensions (WxDxH) | 89 x 119 x 25 mm |
| Interface | RJ-45, SC |
| Power requirements | 7.5V, 1.5A |
| Full duplex | Y |
| Cable type | UTP Cat. 3, 4, 5; 62.5/125μm MM Fiber; 10/125μm SM Fiber |
