Level One LevelOne Konverter GVT-2011 10/100/1000T>1000SX 20km

Kods GVT-2011

Condition: Jauns

Vairāk informācijas

The LevelOne GVT-2011 Gigabit Media Converter Switch provides 1 RJ45 and 2 SFP ports to support conversion between 10/100/1000Base-T and 1000Base-X networks. With the two SFP ports, the converter switch provides high reliability and flexibility to extend the media transmission distance up to 550m, 20km, or longer depending on the SFP fiber optical transceivers. It allows the two types of segment to connect easily, efficiently and inexpensively.The GVT-2011 works in high performance Store and Forward mechanism, and prevent packet loss with IEEE 802.3x Flow Control (Full-Duplex) and Back Pressure (Half-Duplex) functions. As the GVT-2011 Media Converter fully complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T and IEEE 802.3z 1000Base-X, the Gigabit media converter installation is quite quick and easy by simply plug and play.- Transfers data from 10/100/1000Base-T copper to fiber interfaces - SFP slot supports pluggable Gigabit optic modules that enabling you to choose from a variety of transceiver - IEEE 802.3x Flow Control protects against lost packets for reliable data transmission - Supports low-time lag transmission - 10°C to 55°C operating temperature range

Maximum data transfer rate	1000 Mbit/s
Converter input interface	10Base-T, 100Base-TX, 1000Base-T
Converter output interface	1000Base-X
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Jumbo frames support	Y
Jumbo frames	9000
Flow control support	Y
VLAN support	Y
Auto MDI/MDI-X	Y
Auto-negotiation	Y
Store-and-forward	Y
Duplex system	Full, Half
Fiber optic connector	SFP
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Fiber ports quantity	2
DC-in jack	Y
Mean time between failures (MTBF)	30000 h
Internal	N
LED indicators	Activity, Link, Power
Product colour	Grey
Country of origin	China
Certification	FCC, CE
Input voltage	110 - 240 V
Output voltage	5 V
Output current	2 A
Power consumption (max)	5 W
Width	71 mm
Depth	94 mm
Height	26 mm
Weight	300 g
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	5 - 90%
Package width	120 mm
Package depth	235 mm
Package height	55 mm
Package weight	380 g
Package type	Box
AC adapter included	Y
Quick installation guide	Y
Harmonized System (HS) code	85176990
Master (outer) case width	360 mm
Master (outer) case length	480 mm
Master (outer) case height	390 mm
Master (outer) case gross weight	1.2 kg
Products per master (outer) case	36 pc(s)
