| Connectivity technology | Wired |
| Camera included | Y |
| Surveillance camera form factor | Bullet |
| Built-in microphone | N |
| Camera interface | BNC |
| Heat function | N |
| Placement supported | Indoor/outdoor |
| Rotating | N |
| Camera cable length | 18 m |
| Number of cameras | 4 |
| Night mode | Y |
| Night vision distance | 30 m |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 4 mm (1 / 4") |
| LED type | IR |
| Viewing angle | 65° |
| Camera shutter speed | 1/50 - 1/100000 s |
| International Protection (IP) code | IP66 |
| Recorder included | Y |
| Channels quantity | 8 channels |
| Storage media type | HDD |
| Card reader integrated | N |
| Operating system installed | Linux Embedded |
| Optical drive included | N |
| BNC input ports | 8 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| HDD size | 3.5" |
| Number of HDDs supported | 1 |
| HDD capacity | 6000 GB |
| Supported network protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP, HTTPS |
| DC-in jack | Y |
| LED indicators | HDD, LAN, Power |
| Line inputs (RCA) | 1 |
| Line outputs (RCA) | 1 |
| Maximum HDD capacity | 6000 GB |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Playback resolutions supported | 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Ethernet interface type | Fast Ethernet |
| Power source type | DC |
| DC output voltage | 12 |
| Camera power consumption (standby) | 4 W |
| Recorder power consumption (typical) | 8 W |
| Mobile operating systems supported | Android, iOS |
| Operating temperature (T-T) | -40 - 80 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Remote viewing | Y |
| Video compression formats | H.264, MP4 |
| Audio formats supported | G.711 A-law |
| Supported video modes | 720p |
| Web-based management | Y |
| Country of origin | China |
| Product colour | Black, White |
| Pallet net height | 120 cm |
| Pallet net length | 80 cm |
| Pallet net width | 140 cm |
| Certification | CE |
| Camera width | 6.4 cm |
| Camera depth | 16.5 cm |
| Camera height | 6.4 cm |
| Recorder width | 22 cm |
| Recorder depth | 22.2 cm |
| Recorder height | 4.5 cm |
| Width | 225 mm |
| Depth | 430 mm |
| Height | 221 mm |
| Package width | 374 mm |
| Package depth | 154 mm |
| Package height | 308 mm |
| Package weight | 4 kg |
| Power supply included | Y |
| Manual | Y |
| Cables included | DC |
| Package type | Box |
| Quick installation guide | Y |
| Software CD | Y |
