| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Wide Dynamic Range (WDR) | Y |
| Infrared (IR) cut-off filter | Y |
| Number of languages | 33 |
| Dynamic range | 120 dB |
| Certification | FCC, UL |
| Mounting type | Wall |
| Product colour | White |
| Form factor | Bullet |
| LED indicators | Power |
| International Protection (IP) code | IP67 |
| Weatherproof | Y |
| Country of origin | China |
| Field of view (FOV) angle | 83.9° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Sensor type | CMOS |
| Digital zoom | 8x |
| Night vision | Y |
| Night vision distance | 60 m |
| LED type | IR |
| Maximum resolution | 3200 x 1800 pixels |
| Total megapixels | 6 MP |
| Video formats supported | MPEG4 |
| Video compression formats | H.264, H.265 |
| Supported graphics resolutions | 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520, 3200 x 1800 |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Audio system | 1-way |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Bluetooth | N |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| Quality of Service (QoS) support | Y |
| Streaming method | Multicast |
| Live view | Y |
| Built-in HDD | N |
| Card reader integrated | Y |
| Compatible memory cards | MicroSDHC, MicroSDXC |
| Maximum memory card size | 256 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| Active tampering alarm | Y |
| Intelligent Video Surveillance (IVS) system features | Crossing line, Face detection, Human detection, Intrusion, Region entrance detection, Region exiting detection, Vehicle detection |
| Human and vehicle targets classification | Y |
| Web-based management | Y |
| Power source type | PoE |
| AC input voltage | 12 V |
| Power consumption (max) | 9 W |
| Power consumption (Power over Ethernet (PoE)) | 7.5 W |
| Power over Ethernet (PoE) | Y |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64 |
| Mac operating systems supported | Y |
| Width | 386 mm |
| Depth | 155 mm |
| Height | 156 mm |
| Weight | 1.08 kg |
| Package width | 155 mm |
| Package depth | 160 mm |
| Package height | 380 mm |
| Package weight | 1.4 kg |
| Number of cameras | 1 |
| Screws included | Y |
| Manual | Y |
| Resource CD | Y |
| Browser supported | IE 10+, Chrome 57.0+, Firefox 52.0+ |
| Master (outer) cases per pallet (air) | 12 pc(s) |
| Pallet gross width | 120 cm |
| Pallet height (air) | 12.6 m |
| Sustainability compliance | Y |
| Sustainability certificates | CE, RoHS |
| Master (outer) case width | 490 mm |
| Master (outer) case length | 400 mm |
| Master (outer) case height | 460 mm |
| Master (outer) case gross weight | 15 kg |
| Products per master (outer) case | 9 pc(s) |
