| Type | IP security camera | | Placement supported | Outdoor | | Connectivity technology | Wired | | PTZ control | Y | | Wide Dynamic Range (WDR) | Y | | Day/night mode | Y | | Certification | CE, FCC, ONVIF, IP68, IK10, NEMA 4X | | Mounting type | Wall | | Product colour | Silver | | Form factor | Bullet | | LED indicators | Power | | Protection features | Vandal proof | | International Protection (IP) code | IP68 | | IK code | IK10 | | Weatherproof | Y | | Minimum illumination | 0.1 lx | | Lens viewing angle, horizontal | 69.2° | | White balance | Auto | | Camera shutter type | Electronic | | Camera shutter speed | 1/5 - 1/10000 s | | Sensor type | CMOS | | Optical sensor size | 25.4 / 3.2 mm (1 / 3.2") | | Progressive scan | Y | | Number of lenses | 1 | | Zoom capability | Y | | Focus | Manual | | Focal length range | 2.8 - 12 mm | | Focus adjustment | 1.4 | | Night vision | Y | | Night vision distance | 30 m | | LED type | IR | | Number of illumination LEDs | 15 | | Maximum resolution | 2592 x 1944 pixels | | Total megapixels | 5 MP | | Video formats supported | RAW | | Video compression formats | H.264, M-JPEG | | Supported graphics resolutions | 320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2592 x 1944 | | Supported video modes | 240p, 480p, 720p, 1080p | | Frame rate | 30 fps | | Video streaming | Y | | Noise reduction | Y | | Automatic gain control | Y | | Full HD | Y | | Image quality adjustment | Brightness, Contrast, Saturation, Sharpness | | Back Light Compensation (BLC) | Y | | Built-in microphone | N | | Ethernet LAN | Y | | Wi-Fi | N | | Bluetooth | N | | Ethernet interface type | Fast Ethernet | | Supported network protocols | TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour | | Cabling technology | 10/100Base-T(X) | | Built-in HDD | N | | Card reader integrated | Y | | Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC | | Maximum memory card size | 64 GB | | Ethernet LAN (RJ-45) ports | 1 | | Microphone in | Y | | Headphone outputs | 1 | | Terminal block port | Y | | Interface | RJ-45 | | Reset button | Y | | Power source type | PoE | | Power consumption (typical) | 5.76 W | | Power over Ethernet (PoE) | Y | | Operating temperature (T-T) | -40 - 50 °C | | Operating relative humidity (H-H) | 10 - 85% | | Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 | | Width | 77 mm | | Depth | 193 mm | | Height | 73 mm | | Weight | 955 g | | Package width | 285 mm | | Package depth | 202 mm | | Package height | 100 mm | | Package weight | 414 g | | Package type | Box | | Number of cameras | 1 | | Mounting kit | Y | | Mounting brackets included | Y | | Manual | Y | | Quick start guide | Y | | Iris | Y | | Sustainability certificates | RoHS | | Harmonized System (HS) code | 85258900 | | Master (outer) case width | 565 mm | | Master (outer) case length | 410 mm | | Master (outer) case height | 205 mm | | Master (outer) case gross weight | 11.9 kg | | Products per master (outer) case | 8 pc(s) | | Back light compensation method | Y | | Number of video streams | 2 |
|
