| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Day/night mode | Y |
| Infrared (IR) cut-off filter | Y |
| Certification | CE, FCC |
| Mounting type | Ceiling/wall |
| Product colour | White |
| Form factor | Dome |
| LED indicators | Power |
| Protection features | Vandal proof |
| International Protection (IP) code | IP66 |
| IK code | IK10 |
| Country of origin | China |
| Minimum illumination | 0.01 lx |
| Field of view (FOV) angle | 83° |
| Camera shutter speed | 1/3 - 1/10000 s |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Progressive scan | Y |
| Number of lenses | 1 |
| Fixed focal length | 4 mm |
| Night vision | Y |
| Night vision distance | 30 m |
| LED type | IR |
| Maximum resolution | 2560 x 1920 pixels |
| Total megapixels | 5 MP |
| Video formats supported | RAW |
| Video compression formats | H.264, M-JPEG |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2560 x 1920 |
| Frame rate | 20 fps |
| Full HD | Y |
| Image quality adjustment | Brightness, Contrast, Saturation |
| Privacy masking | Y |
| Audio formats supported | G.711, G.726 |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Bluetooth | N |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u |
| Supported network protocols | TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour |
| Cabling technology | 10/100Base-T(X) |
| Number of users | 10 user(s) |
| Built-in HDD | N |
| Card reader integrated | Y |
| Compatible memory cards | MicroSDHC, MicroSDXC |
| Maximum memory card size | 128 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| Terminal block port | Y |
| DC-in jack | Y |
| Interface | RJ-45 |
| IP address filtering | Y |
| Web-based management | Y |
| Reset button | Y |
| Power source type | PoE |
| AC input voltage | 12 V |
| Power consumption (max) | 5 W |
| Power over Ethernet (PoE) | Y |
| Operating temperature (T-T) | -30 - 60 °C |
| Windows operating systems supported | Y |
| Height | 82 mm |
| Diameter | 11.1 cm |
| Weight | 500 g |
| Package width | 134 mm |
| Package depth | 134 mm |
| Package height | 108 mm |
| Package weight | 530 g |
| Package type | Box |
| Number of cameras | 1 |
| Screws included | Y |
| Resource CD | Y |
| Audio input | Y |
| Removable IR-cut filter | Y |
| Sustainability certificates | RoHS |
| Master (outer) case width | 345 mm |
| Master (outer) case length | 288 mm |
| Master (outer) case height | 568 mm |
| Master (outer) case gross weight | 12.7 kg |
| Products per master (outer) case | 24 pc(s) |
