Delock 3 Port USB 3.1 Gen 1 Hub with USB Type-C™ Connection and Gigabit LAN

Kods 64043

Condition: Jauns

Vairāk informācijas

The USB hub by Delock is the mobile companion for laptops or tablets with USB Type-C™ connection. Up to 2 USB Type-A devices and one USB-C™ device can be connected to the hub.

Integrated 10/100/1000 Mbps LAN interface
In addition, the hub with integrated RJ45 Gigabit LAN connection expands a PC or laptop by a network interface via the USB Type-C™ connection.

Small sturdy helper
Due to its small dimensions and its sturdy housing, this Delock Hub is particularly suitable for travelling. It can simply be packed into the bag together with the laptop or tablet and used as needed.

System requirements:
• Chrome OS
• Linux Kernel 4.9.4 or above
• Mac OS 10.13.6 or above
• Windows 7/7-64/8.1/8.1-64/10/10-64
• Laptop or tablet with a free USB Type-C™ or Thunderbolt™ 3 port

Specification:
• Connectors:
  1 x SuperSpeed USB (USB 3.1 Gen 1) USB Type-C™ male >
  2 x SuperSpeed USB (USB 3.1 Gen 1) Type-A female
  1 x SuperSpeed USB (USB 3.1 Gen 1) USB Type-C™ female
  1 x Gigabit LAN RJ45 jack
• Chipset: Genesys Logic GL3510, VIA VL160, Realtek RT8153
• Data transfer rate:
  USB 3.0 up to 5 Gbps
  Ethernet up to 10 Mbps (Half/Full Duplex)
  Fast Ethernet up to 100 Mbps (Half/Full Duplex)
  Gigabit Ethernet up to 1000 Mbps (Half/Full Duplex)
• Compatible with:
  IEEE 802.3: 10BASE-T
  IEEE 802.3u: 100BASE-TX
  IEEE 802.3ab: 1000BASE-T
• Supports Auto MDI-X (automatic detection of standard or crossover network cable)
• Supports IEEE 802.3az (Energy Efficient Ethernet)
• Supports IEEE 802.1Q Virtual LAN (VLAN)
• Support full duplex operation with IEEE 802.3x flow control and half duplex
operation with back-pressure flow control
• Supports 4k Jumbo Frames
• 1 x ferrite core
• Cable length without connectors: ca. 20 cm
• Dimensions (LxWxH): ca. 54 x 54 x 13 mm
• Plug & Play

Package content:
• USB hub + LAN
• User manual

Data sheet:
http://www.delock.de/produkt/64043/pdf.html?sprache=en
