| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Jā |
| Web-based management | Jā |
| Basic switching RJ-45 Ethernet ports quantity | 28 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Combo SFP ports quantity | 4 |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Nē |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T, 1000BASE-X |
| Port mirroring | Jā |
| Full duplex | Jā |
| Flow control support | Jā |
| Link aggregation | Jā |
| Broadcast storm control | Jā |
| Rate limiting | Jā |
| MAC address auto-learning supported | Jā |
| MAC address auto-aging supported | Jā |
| VLAN support | Jā |
| Virtual LAN features | Port-based VLAN, Tagged VLAN |
| Number of VLANs | 32 |
| MAC address table | 8000 entries |
| Switching capacity | 56 Gbit/s |
| Jumbo frames support | Jā |
| Jumbo frames | 9000 |
| Packet buffer memory | 4.1 MB |
| IGMP snooping | Jā |
| Queue scheduling algorithms | Priority queuing (PQ) |
| Multicast support | Jā |
| Rack mounting | Jā |
| Product colour | Black |
| LED indicators | Power, Link, Activity |
| International Protection (IP) code | IP30 |
| Country of origin | China |
| Flash memory | 2 MB |
| Fanless | Jā |
| Mean time between failures (MTBF) | 43800 h |
| Layers per pallet (air) | 16 pc(s) |
| Pallet gross length | 80 cm |
| Pallet gross width | 120 cm |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS, UKCA |
| Power source | DC |
| Power supply included | Nē |
| Redundant power supply (RPS) support | Jā |
| DC input voltage | 12 - 57 V |
| Power consumption (typical) | 20 W |
| Surge protection | Jā |
| Surge protection voltage | 4 kV |
| Power protection features | Surge protection |
| Power over Ethernet (PoE) | Nē |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 68.24 BTU/h |
| Width | 440 mm |
| Depth | 244 mm |
| Height | 45 mm |
| Weight | 3.4 kg |
| Quick start guide | Jā |
| Terminal block included | Jā |
| Package type | Box |
| Rack mount kit | Jā |
| Package width | 510 mm |
| Package depth | 375 mm |
| Package height | 93 mm |
| Package weight | 4 kg |
| Sustainability certificates | CE, Federal Communications Commission (FCC), RoHS, UKCA |
| Pallet gross height | 174.4 cm |
| Master (outer) case width | 540 mm |
| Master (outer) case length | 320 mm |
| Master (outer) case height | 400 mm |
| Harmonized System (HS) code | 8517620090 |
| Master (outer) case gross weight | 12.5 kg |
| Products per master (outer) case | 3 pc(s) |
| Sustainability compliance | Jā |
