| Switch type | Unmanaged |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Fast Ethernet (copper) ports quantity | 8 |
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX |
| Full duplex | Y |
| Half duplex | Y |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| Auto-negotiation | Y |
| MAC address table | 8000 entries |
| Switching capacity | 1.6 Gbit/s |
| Packet buffer memory | 1 MB |
| Product colour | Black |
| LED indicators | Activity, Link, Power |
| Wall mountable | Y |
| DIN rail mounting | Y |
| Power source | AC/DC |
| Power supply included | Y |
| Input voltage | 12 - 60 V |
| Surge protection | Y |
| Surge protection voltage | 8 kV |
| Power over Ethernet (PoE) | N |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Width | 165 mm |
| Depth | 114 mm |
| Height | 50 mm |
| Weight | 450 g |
| Quick start guide | Y |
| Terminal block included | Y |
| Sustainability compliance | Y |
| Sustainability certificates | CE, Federal Communications Commission (FCC) |
| Terminal block port | Y |
