| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 1 |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | N |
| Full duplex | Y |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| Auto-negotiation | Y |
| MAC address table | 1024 entries |
| Switching capacity | 12 Gbit/s |
| Store-and-forward | Y |
| Jumbo frames | 10000 |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Packet forwarding rate (100 Mbps) | 148000 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet buffer memory | 1 MB |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Activity, Link, Power |
| International Protection (IP) code | IP30 |
| Wall mountable | Y |
| DIN rail mounting | Y |
| Country of origin | Taiwan |
| Certification | FCC Part 15 Subpart B Class A CE EN 55022 Class A EN61000-4-2 (ESD) Level 3 EN61000-4-3 (RS) Level 3 EN61000-4-4 (EFT) Level 3 EN61000-4-5 (Surge) Level 3 EN61000-4-6 (CS) Level 3 EN61000-4-8 (Magnetic Field) Level 3 UL508 (Pending) EN 50121-4 (Pending) IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 UL 508 |
| Input voltage | 5 - 56 V |
| Power protection features | Overload, Reverse polarity |
| Power over Ethernet (PoE) | N |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Width | 40 mm |
| Depth | 105 mm |
| Height | 38 mm |
| Weight | 720 g |
| Quick start guide | Y |
| Package type | Box |
| Package width | 215 mm |
| Package depth | 165 mm |
| Package height | 65 mm |
| Package weight | 120 g |
| Harmonized System (HS) code | 85176990 |
| Terminal block port | Y |
