| Switch type | Unmanaged |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable types supported | Cat5 |
| Full duplex | Y |
| MAC address table | 8192 entries |
| Switching capacity | 32 Gbit/s |
| Store-and-forward | Y |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Packet forwarding rate (100 Mbps) | 148000 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Rack mounting | Y |
| Stackable | N |
| Product colour | Grey |
| LED indicators | Activity, Link, PoE, Power |
| Country of origin | Taiwan |
| Certification | FCC Part 15 Class A, CE, RoHS |
| Buffer size | 256 KB |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 500 W |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Total Power over Ethernet (PoE) budget | 480 W |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Width | 480 mm |
| Depth | 200 mm |
| Height | 44 mm |
| Weight | 3.4 kg |
| Cables included | AC |
| Quick start guide | Y |
| Package type | Box |
| Package width | 260 mm |
| Package depth | 96 mm |
| Package height | 540 mm |
| Package weight | 4 kg |
| Harmonized System (HS) code | 85176990 |
