Level One LevelOne Switch 8x GE IGP-1221 4xGSFP 240W 8XPoE

Kods IGP-1221

Condition: Jauns

Vairāk informācijas

The LevelOne IGP-1221 Industrial Gigabit PoE Switch provides 8 ports of Gigabit RJ45 PoE and 4 ports of Gigabit SFP to enable high speed network at mission-critical environment. The switch is IEEE 802.3af/at compliant, providing power and data over a single Ethernet cable to any PoE device, with a total power budget of 240W, or up to 30W per port. With an industrial-standard DIN-rail mount for easy cabinet deployment, this ruggedized switch is engineered for installation in industrial settings where humidity, dust, high or low operating temperatures or vibrations could cause standard devices to fail.- IEEE 802.3af/at PoE compliant to simplify deployment and installation - Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az) - 10/100/1000Mbps wire speed transmission and reception - 40°C to 75°C operating temperature range

Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	8
SFP module slots quantity	4
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u
10G support	N
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
MAC address table	8000 entries
Switching capacity	24 Gbit/s
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	9216
Packet buffer memory	0.5 MB
Product colour	Grey
Reset button	Y
LED indicators	System
DIN rail mounting	Y
Country of origin	Taiwan
Safety	UL,CB
Certification	FCC,CE
Internal memory	128 MB
Flash memory	32 MB
Mean time between failures (MTBF)	512345 h
DC input voltage	48 - 57 V
Power consumption (max)	238.16 W
Power protection features	Short circuit
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	8
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	240 W
Operating temperature (T-T)	-40 - 75 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%
Width	62 mm
Depth	130 mm
Height	135 mm
Weight	700 g
Quick start guide	Y
Manual	Y
Package type	Box
Package width	255 mm
Package depth	207 mm
Package height	85 mm
Package weight	900 g
Master (outer) case width	520 mm
Master (outer) case length	445 mm
Master (outer) case height	220 mm
Harmonized System (HS) code	85176990
Master (outer) case gross weight	2.4 kg
Products per master (outer) case	10 pc(s)
