Level One LevelOne Switch 8x GE GEP-0823 120W 8xPoE+

Kods GEP-0823

Condition: Jauns

Vairāk informācijas

The LevelOne GEP-0823 is an 8-port Gigabit Ethernet PoE switch that provides Power over Ethernet on all eight of its ports. Per PoE port a power supply of up to 30W is possible. The total PoE power budget is 120W. It is the ideal solution when office and home users are using a combination of PoE and non-PoE devices.The GEP-0823\'s eight PoE-enabled ports make it an ideal solution for office users who use PoE-enabled devices and already want to power a larger number of PoE devices. These products can be a mix of PoE IP phones, PoE Wifi APs and PoE IP cams. It is the perfect solution for offices that want to upgrade their office equipment and LAN infrastructure to PoE capability or upgrade their existing PoE infrastructure to Gigabit speed. The switch automatically detects the connected IEEE 802.3at/af standard device and provides these devices with power and data over a single cable.The GEP-0823 also enables users to provide a stable and reliable high-speed LAN environment with store-and-forward switching architecture, packet error filtering and blockade-free packet forwarding. The 802.3x flow control mechanisms operate in both full and half duplex modes. This switch also supports the N-Way auto negotiation protocol, which automatically detects network speed and duplex mode.For instant fault detection, the GEP-0823 is equipped with a complete set of LEDs to help monitor and troubleshoot the network.

Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power connector	DC-in jack
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G support	N
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Full duplex	Y
MAC address table	8000 entries
Switching capacity	16 Gbit/s
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	9126
Stackable	N
Product colour	Black
Housing material	Metal
LED indicators	Activity, LAN, Power
Country of origin	China
Certification	CE,FCC
Internal memory	1 MB
Buffer size	8 KB
Mean time between failures (MTBF)	30000 h
Input current	2.5 A
Input voltage	52 V
Power consumption (typical)	10 W
Power protection features	Over current, Short circuit
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	8
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	120 W
Operating temperature (T-T)	-20 - 70 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	5 - 90%
Storage relative humidity (H-H)	5 - 90%
Width	86 mm
Depth	30 mm
Height	176 mm
Weight	450 g
Quick start guide	Y
AC adapter included	Y
Package width	230 mm
Package depth	60 mm
Package height	290 mm
Package weight	950 g
Harmonized System (HS) code	85176990
