| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Y |
| Traffic classification | Y |
| System event log | Y |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 2 |
| Fiber ports quantity | 2 |
| Fiber optic connector | SFP |
| Console port | RJ-45 |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | N |
| Port mirroring | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Spanning tree protocol | Y |
| Cable length detection | Y |
| VLAN support | Y |
| Virtual LAN features | MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Tagged VLAN |
| Number of VLANs | 4000 |
| Fiber ethernet cabling technology | 100BASE-X, 1000BASE-X |
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Forwarding rate | 14.9 Mpps |
| Store-and-forward | Y |
| Number of trunks | 8 |
| Number of queues | 8 |
| Static route | Y |
| Jumbo frames support | Y |
| Jumbo frames | 10000 |
| Packet buffer memory | 4.1 MB |
| DHCP features | DHCP client, DHCP snooping |
| Access Control List (ACL) | Y |
| Access Control List (ACL) rules | 512 |
| IGMP snooping | Y |
| MAC address filtering | Y |
| SSH/SSL support | Y |
| BPDU filtering/protection | Y |
| Password protection | Y |
| DoS attack prevention | Y |
| Multicast support | Y |
| IPv4 & IPv6 features | IPv6 Telnet, IPv6 ping, IPv6 tracert |
| Rack mounting | Y |
| Stackable | N |
| Product colour | Black |
| Reset button | Y |
| LED indicators | Activity, Link, Power |
| Country of origin | China |
| Certification | CE class A, FCC, UL, VCCI, BSMI |
| Internal memory | 32 MB |
| Telnet | Y |
| Power source | AC |
| Power supply included | Y |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 80 W |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 125 W |
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Width | 181 mm |
| Depth | 270 mm |
| Height | 44 mm |
| Weight | 800 g |
| Cables included | AC, LAN (RJ-45) |
| Quick start guide | Y |
| Package type | Blister |
| Rack mount kit | Y |
| Resource CD | Y |
| Package width | 255 mm |
| Package depth | 82 mm |
| Package height | 345 mm |
| Package weight | 2 kg |
| Harmonized System (HS) code | 85176990 |
