Level One LevelOne Switch 16x FE FSW-1650 19"

Kods FSW-1650

Condition: Jauns

Vairāk informācijas

Product Overview The FSW-1650 switch provides an ideal solution for small businesses that demand a reliable network switch that provides a high bandwidth interface between file servers and workgroups, departments and offices.Advanced Networking Features The LevelOne FSW-1650 is a wire-speed, nonblocking 16 port Fast Ethernet Unmanaged Switch with an internal power supply. It provides a network with an 8K MAC address table, 3.2Gbps backplane throughput, asymmetrical flow-control support for full-duplex network connectivity, auto-negotiation and Auto-MDIX.The 16-port Fast Ethernet Switch utilizes packetstore- and forwarding switching for error-free data transmissions and IEEE802.3x backpressure flow control to control data flow between the sending and receiving nodes as well as to prevent any data packet loss.Compact Design The FSW-1650 is a compact designed network switch. Users can place the switch on any desktop area or mount it in a 19-inch server rack or cabinet by using the included rack-mounting accessory kit.Quick Configuration and Easy Maintenance The LevelOne FSW-1650 does not require any software configuration. It is Plug-and-Play enabled for quick set-up and immediate use within the Local Area Network. The 16 port Faster Ethernet Switch is equipped with a full range of LEDs for instant error detection, networking monitoring and network troubleshooting.- Provides flexibility of 16 x 10/100BASE-TX ports - 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX - Supports 8K MAC address auto-learning and auto-aging - QoS control for traffic prioritization and bandwidth management - IEEE 802.3x Flow Control protects against lost packets for reliable data transmission - 19-inch metal housing - Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)

Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support	N
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Cable types supported	Cat5
Full duplex	Y
MAC address table	8192 entries
Switching capacity	3.2 Gbit/s
Store-and-forward	Y
Switching protocols	CSMA/CD
Rack mounting	Y
Stackable	N
Product colour	Grey
LED indicators	Activity, LAN, Link, Power
Country of origin	China
Certification	CE RoHS
Buffer size	160 KB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	6.2 W
Power over Ethernet (PoE)	N
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 95%
Width	44 mm
Depth	208 mm
Height	440 mm
Weight	2.6 kg
Cables included	AC
Quick start guide	Y
Wall mounting kit	Y
Package width	308 mm
Package depth	94 mm
Package height	550 mm
Package weight	2.7 kg
Harmonized System (HS) code	85176990
