| Switch type | Unmanaged |
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 1 |
| Fiber optic connector | SFP |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable types supported | Cat5, Cat5e |
| Full duplex | Y |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| Auto-negotiation | Y |
| MAC address auto-learning supported | Y |
| MAC address auto-aging supported | Y |
| Fiber ethernet cabling technology | 1000BASE‑LX, 1000BASE‑SX |
| Transmission distance (max) | 0.55 km |
| MAC address table | 4000 entries |
| Switching capacity | 1 Gbit/s |
| Store-and-forward | Y |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Packet forwarding rate (100 Mbps) | 148800 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet buffer memory | 1 MB |
| Rack mounting | N |
| Product colour | Grey |
| Housing material | Metal |
| LED indicators | Activity, Link, Power |
| Wall mountable | Y |
| Country of origin | China |
| Certification | FCC Class B, CE |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 2.5 A |
| Power over Ethernet (PoE) | N |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 90 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Width | 96 mm |
| Depth | 112 mm |
| Height | 30 mm |
| Weight | 380 g |
| Quick start guide | Y |
| AC adapter included | Y |
| Rubber feet | Y |
| Package width | 140 mm |
| Package depth | 250 mm |
| Package height | 55 mm |
| Package weight | 540 g |
| Harmonized System (HS) code | 85176990 |
