> >>Level One LevelOne MiniGBIC GVT-0301 SFP LX/LC Fiber SM 10km
Level One LevelOne MiniGBIC GVT-0301 SFP LX/LC Fiber SM 10km

Level One LevelOne MiniGBIC GVT-0301 SFP LX/LC Fiber SM 10km

LEVEL ONE

GVT-0301

Jauns

Product Overview The LevelOne GVT-0301 SFP (Small form-factor pluggable) Transceiver provide flexibility for utilizing fiber Gigabit network connections in both data and telecommunication applications.Support for Mini GBIC Connectivity GVT-0301 SFP Transceiver Series transceivers support LX standard optic with single-mode mini GBIC connectors. They provide signal amplification to transfer and receive data between two ends of mini GBIC ports.Multi-Purpose Usage GVT-0301 SFP transceivers can be used for distributed multi-processing, switch-to-switch interfaces, high-speed I/O file transfer, bus extension applications, and for a channel extender or data storage applications. The LevelOne GVT-0301 can be used in any LevelOne switch or modules that support SFP modules.- Add a 1000Base-LX connection to LevelOne switchs with mini GBIC/SFP ports - Connect switches up to 10km away with each other - TTL signal detect indicator - Compliant with IEEE802.3z Gigabit Ethernet - Easy to install and hot-swappable - Differential LVPECL input and output - Single 3.3V power supply - Duplex LC connector

SFP transceiver typeFiber optic
Maximum data transfer rate1250 Mbit/s
Interface typeSFP
Single-mode fiber (SMF) supportedY
Fiber optic connectorLC
Fiber cable diameters supported (core/cladding)9/125 µm
SFP transceiver standardLX
Maximum transfer distance10000 m
Wavelength1310 nm
Tx power (min)-9.5 dBmW
Tx power (max)-3 dBmW
Link budget10.5 dB
Networking standardsIEEE 802.3z
Hot-Plug supportY
Country of originTaiwan
Compatible productsGSW-2453 GVT-4000
CertificationClass 1 Laser: EN60825-1 FDA 21: 1040.10, 1040.11
Input voltage3.5 V
Maximum voltage6 V
Maximum current0.3 A
Operating temperature (T-T)0 - 70 °C
Operating relative humidity (H-H)5 - 90%
Width13.5 mm
Depth55.5 mm
Height8.5 mm
Number of products included1 pc(s)
Package width70 mm
Package depth50 mm
Package height130 mm
Package weight70 g
Harmonized System (HS) code85369010
