Delock Coaxial DisplayPort cable 16K 60 Hz 80 Gbps 1 m

Delock Coaxial DisplayPort cable 16K 60 Hz 80 Gbps 1 m

DELOCK

80491

Jauns

This coaxial DisplayPort cable by Delock is used to connect devices with a DisplayPort interface, such as monitors, projectors or televisions, to a PC or laptop.

Ideal for gamers
By supporting a maximum bandwidth of 80 Gbps, content up to 16K @ 60 Hz resolution can be displayed, a refresh rate of up to 120 Hz is possible at 8K resolution and even up to 240 Hz at 4K resolution.
Due to the HDR10 support colours are realistically displayed with impressive depth, brightness and contrast are optimally reproduced.


The high-quality, triple-shielded cable also significantly improves the quality of audio transmissions with a sampling rate of up to 1536 kHz.
System requirements:
• A free DisplayPort interface
Specification:
• Connectors: 2 x DisplayPort male
• DisplayPort 2.1 specification
• Downwards compatible to DisplayPort 2.0, 1.4, 1.3, 1.2 and 1.1
• Pin 20 not connected
• Cable gauge: 30 AWG
• Cable type: coaxial
• Cable diameter: ca. 5.8 mm
• Triple shielded cable
• Contacts gold-plated
• Transmission of audio and video signals
• Data transfer rate up to 80 Gbps
• Resolution up to:
  15360 x 8640 @ 60 Hz
  10240 x 4320 @ 60 Hz
  7680 x 4320 @ 120 Hz
  3840 x 2160 @ 240 Hz
  3840 x 2160 @ 144 Hz
  (depending on the system and the connected hardware)
• Supports Display Stream Compression 1.2a (DSC)
• Supports HDR10
• Supports HDCP 1.4 and 2.3
• Supports UHBR 20 (20 Gbps / Lane) data rate
• Up to 32 audio channels for speakers
• Up to 1536 kHz audio sampling rate
• Supports colour sampling in 4:4:4, 4:2:2 and 4:2:0 format
• Colour: black
• Length incl. connectors: ca. 1 m
Package content:
• DisplayPort cable
Data sheet:
http://www.delock.de/produkt/80491/pdf.html?sprache=en
