Connectors - Connector A: DisplayPort (Male)
- Connector B: DisplayPort (Male)
- Housing Material: PVC
- Connector Plating: Gold Plated
- Pin Construction: Gold Plated
- Pin Plating: Gold Plated
- Dimensions (approx.) WxDxH: DP Connector: 19.8x47.8x12mm (0.78x1.88x0.47in)
Cable Construction - Length: 10m (32.81ft)
- Standard: DisplayPort 2.0
- Colour: Black
- Type: Round
- Jacket Diameter: 4.0mm (0.16in)
- Jacket Material: PVC
- Conductor Material: Fiber and Copper
- Conductor Gauge: 24AWG
- Shielding: -
Specifications - Supported Bandwidth: 40Gbps
- Maximum Resolution: 7680x4320@60Hz 4:2:0 10bit, 3840x2160@144Hz 4:4:4 10bit
- Nominal Attenuation: ≤10dB/km@850nm, ≤8dB/km@1300nm
- Minimum Bend Radius: 50mm (1.97in)
- Operating Temperature: -10°C - 60°C (14°F - 140°F)
- Storage Temperature: -20°C - 70°C (-4°F - 158°F)
Miscellaneous - Packaging Type: Carton Box
- Warranty (Years): 2
- Certificated: CE, UKCA, FCC, RoHS, REACH & California Proposition 65
Purchasing Information - No.: 38520
- EAN: 4002888385206
This product is also available in other lengths: - 38521 - 15m (49.21ft)
- 38522 - 20m (65.62ft)
- 38523 - 30m (98.42ft)
- 38524 - 40m (131.23ft)
- 38525 - 50m (164.04ft)
|
