| Connectivity technology | Wireless | | Host interface | USB | | Interface | WLAN | | USB version | 2.0 | | Maximum data transfer rate | 433 Mbit/s | | Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac | | Wi-Fi | Y | | Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) | | Frequency range | 2.4 - 5 GHz | | Top Wi-Fi standard | Wi-Fi 5 (802.11ac) | | Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) | | WLAN data transfer rates supported | 11,54,150,433 Mbit/s | | Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM | | Security algorithms | WEP, WPA, WPA-PSK, WPA2, WPA2-PSK | | Internal | N | | Component for | PC/notebook | | Product colour | Black | | Antenna | Y | | LED indicators | Status | | Receiver sensitivity | 11a 6Mbps: -94dBm 11a 54Mbps: -78dBm 11n HT20 MCS0: -94dBm 11n HT20 MCS7: -77dBm 11n HT40 MCS0: -92dBm 11n HT40 MCS7: -74dBm 11ac VHT80 MCS0: -89dBm 11ac VHT80 MCS9: -64dBm 11b 1Mbps: -99dBm 11b 11Mbps: -91dBm 11g 6Mbps: -94dBm 11g 54Mbps: -77dBm 11n HT20 MCS0: -95dBm 11n HT20 MCS7: -76dBm 11n HT40 MCS0: -92dBm 11n HT40 MCS7: -73dBm | | Certification | CE, FCC | | Windows operating systems supported | Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 | | Operating temperature (T-T) | 0 - 40 °C | | Storage temperature (T-T) | -40 - 70 °C | | Operating relative humidity (H-H) | 10 - 90% | | Storage relative humidity (H-H) | 5 - 90% | | Sustainability certificates | RoHS | | Width | 40.5 mm | | Depth | 19.7 mm | | Height | 10.3 mm | | Harmonized System (HS) code | 85176990 | | Housing material | Plastic | | Quick start guide | Y |
|
