> >>WL-AP TP-Link Access Point TL-WA1201 (300MBit)
Jauns WL-AP TP-Link Access Point TL-WA1201 (300MBit)

WL-AP TP-Link Access Point TL-WA1201 (300MBit)

TP-LINK

TL-WA1201

Jauns



2.4 GHzY
5 GHzY
6 GHzN
Maximum data transfer rate867 Mbit/s
Maximum data transfer rate (2.4 GHz)300 Mbit/s
Maximum data transfer rate (5 GHz)867 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Cabling technology10/100/1000Base-T(X)
MIMOY
MIMO typeMulti User MIMO
Fit AP mode featuresWireless distribution system (WDS)
Wi-Fi Multimedia (WMM)/(WME)Y
Quality of Service (QoS) supportY
Transmitting power (CE)<20dBm(2.4GHz), <23dBm(5.15GHz~5.25GHz)
Transmitting power (FCC)<30dBm(2.4GHz&5GHz)
Receiver sensitivity5 GHz: , 11a 6 Mbps: -95 dBm, 11a 54 Mbps: -81 dBm , 11ac VHT20(MCS0): -94 dBm, 11ac VHT20(MCS8): -71 dBm , 11n HT40(MCS0): -91 dBm, 11n HT40(MCS7): -71 dBm , 11ac VHT80(MCS0): -88 dBm, 11ac VHT80(MCS9): -63 dBm , , 2.4 GHz: , 11g 54Mbps: -78 dBm , 11n HT20(MCS0): -92 dBm, 11n HT20(MCS7): -74 dBm , 11n HT40(MCS0): -88 dBm, 11n HT40(MCS7): -72 dBm
Security algorithms64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) featuresMultiple SSIDs
Device type identificationDHCP options
Auto Wireless Distribution System (WDS)Y
Access Control List (ACL)Y
DHCP serverY
DHCP clientY
Supported network protocolsIPv4, IPv6
Web-based managementY
Firmware upgradeableY
Ethernet LAN (RJ-45) ports1
WAN connectionEthernet (RJ-45)
DC-in jackY
Power over Ethernet (PoE)Y
Output voltage12 V
Output current1.5 A
PlacementTable
Product colourWhite
On/off switchY
Reset buttonY
WPS push buttonY
LED indicatorsY
CertificationCE, FCC, RoHS
Antenna typeExternal
Antennas quantity4
Compatible operating systemsMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux
Width225 mm
Depth145.5 mm
Height37 mm
Package width400 mm
Package depth255 mm
Package height69 mm
Package weight860 g
Package typeBox
Number of products included1 pc(s)
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)5 - 90%
