Level One LevelOne WL-AP WAP-8123 1200Mbps MIMO PoE

LEVEL ONE

WAP-8123

Jauns

The LevelOne WAP-8123 is a standalone, AC1200 dual-band Wi-Fi 5 PoE wireless access point that features dual Gigabit Ethernet ports and advanced 802.11ac Wave 2 MU-MIMO (Multi-User Multiple-Input Multiple-Output), allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. capable of a combined speed of up to 1200 Mbps.The WAP-8123 provides 2.4 and 5 GHz frequencies and can be used as a high-quality stand-alone access point in a corporate environment or for demanding installations. It also offers support for the new WPA3 encryption. Of course, the WAP-8123 is also equipped with PoE, which eliminates the need for an external power supply, simplifying installation. A fast, versatile and secure access point for a variety of network requirements, especially when high speeds are important for many users.

2.4 GHzY
5 GHzY
6 GHzN
Maximum data transfer rate1200 Mbit/s
Maximum data transfer rate (2.4 GHz)300 Mbit/s
Maximum data transfer rate (5 GHz)867 Mbit/s
Frequency band2.412 - 2.484, 5.18 - 5.825 GHz
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at
Channels quantity165 channels
MIMOY
MIMO typeMulti User MIMO
Operating modesGateway, AP, Repeater
Security algorithmsWPA2, WPA3
Number of SSID supported8
Web-based managementY
Ethernet LAN (RJ-45) ports2
DC-in jackY
Power over Ethernet (PoE)Y
Power consumption (typical)20 W
PlacementCeiling
Product colourWhite
Country of originChina
Antenna typeInternal
Antennas quantity2
Flash memory16 MB
Internal memory128 MB
Master (outer) cases per pallet (air)10 pc(s)
Pallet gross length80 cm
Pallet gross width120 cm
Pallet height (air)162 cm
Width198 mm
Depth28 mm
Height198 mm
Weight520 g
Package width235 mm
Package depth76 mm
Package height243 mm
Package weight830 g
Package typeBox
Cables includedLAN (RJ-45)
Quick start guideY
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)0 - 70 °C
Storage relative humidity (H-H)5 - 95%
Sustainability complianceY
Sustainability certificatesCE, RoHS
Master (outer) case width506 mm
Master (outer) case length410 mm
Master (outer) case height491 mm
Master (outer) case gross weight18 kg
Products per master (outer) case20 pc(s)
