Level One LevelOne WLAN Access Point & Extender outdoor PoE 5GHz N300

LEVEL ONE

WAB-5010

Jauns

The LevelOne WAB-5010 is a managed, outdoor single-band 802.11a/n wireless access point, capable of 300 Mbps wireless internet speeds. The device runs on 5 GHz frequency, and can be used as part of a managed network when controlled by the LevelOne WAC-2000/WAC-2003 Wireless LAN Controller. LevelOne WAB-5010 also offers PoE, removing the need for an external power supply, which makes it easy to install. Advanced weatherproof design, rated to IP65 means the WAP is designed for outdoor deployments, and can withstand rain, humidity, dust, snow and extremely hot conditions. A fast, versatile and secure access point for a wide variety of outdoor network requirements.Key Features - Share your wireless network up to 300Mbps - Multi-operation modes to suit different wireless applications - IEEE 802.3af/at PoE compliant to simplify deployment and installation - Weatherproof IP65-rated housing - Provides up to 4 SSIDs to separate network traffic and enhance security

2.4 GHzN
5 GHzY
Maximum data transfer rate300 Mbit/s
Ethernet LAN data rates10,100 Mbit/s
Frequency band5.18 - 5.825 GHz
Networking standardsIEEE 802.11a, IEEE 802.11e, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Number of users64 user(s)
Channels quantity165 channels
Modulation16-QAM, 64-QAM, BPSK, CCK, DSSS, OFDM, QPSK
Wi-Fi Multimedia (WMM)/(WME)Y
Operating modesAccess Point (AP),Gateway,Repeater,WDS,WISP
Quality of Service (QoS) supportY
Security algorithms64-bit WEP, 128-bit WEP, WPA-AES, WPA-TKIP, WPA2-AES, WPA2-TKIP, WPS
Service Set Identifier (SSID) featuresSSID broadcast on/off
Number of SSID supported4
Auto Wireless Distribution System (WDS)Y
Web-based managementY
Firmware upgradeableY
Ethernet LAN (RJ-45) ports1
WAN connectionEthernet (RJ-45)
Power over Ethernet (PoE)Y
AC input voltage12 V
Input current1.5 A
Power consumption (typical)15 W
Product colourWhite
International Protection (IP) codeIP65
Reset buttonY
Country of originChina
CertificationCE, FCC
InternalN
Antenna featuresIntegrated antenna
Antenna gain level (max)15 dBi
Width87 mm
Depth257 mm
Height40 mm
Weight440 g
CD manualY
CD quick installation guideY
Package width106 mm
Package depth332 mm
Package height95 mm
Package weight700 g
Package typeBox
Cables includedLAN (RJ-45)
Mounting kitY
Quick start guideY
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)-40 - 55 °C
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)5 - 90%
Harmonized System (HS) code85176990
Master (outer) case width350 mm
Master (outer) case length495 mm
Master (outer) case height452 mm
Master (outer) case gross weight2.1 kg
Products per master (outer) case20 pc(s)
