Type | Network transmitter & receiver |
Data transfer rate | 1167 Mbit/s |
Ethernet LAN data rates | 10,100 Mbit/s |
WPS push button | Y |
Plug and Play | Y |
Antennas quantity | 2 |
Antenna type | External |
Cabling technology | 10/100Base-T(X) |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab |
Wi-Fi | Y |
Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Wi-Fi data rate (max) | 1167 Mbit/s |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
Security algorithms | WPA, WPA2 |
Web-based management | Y |
Ethernet LAN (RJ-45) ports | 1 |
Product colour | White |
LED indicators | Signal strength, Status, WPS |
Reset button | Y |
Certification | FCC, CE, UL, IC |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Operating temperature (T-T) | 0 - 35 °C |
Storage temperature (T-T) | -20 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Width | 97.9 mm |
Depth | 50.7 mm |
Height | 48.7 mm |
Weight | 120 g |
Shipping (inner) case height | 35.7 cm |
Shipping (inner) case width | 22.7 cm |
Shipping (inner) case length | 50.1 cm |
Shipping (inner) case net weight | 6.26 kg |
Products per shipping (inner) case | 20 pc(s) |
Pallet gross weight (air) | 221.4 kg |
Master (outer) cases per pallet (air) | 30 pc(s) |
Products per pallet (air) | 600 pc(s) |
Pallet gross length | 120 cm |
Pallet gross width | 110 cm |
Pallet height (air) | 120.6 cm |
Pallet gross weight (sea) | 361 kg |
Master (outer) cases per pallet (sea) | 50 pc(s) |
Products per pallet (sea) | 1000 pc(s) |
Pallet height (sea) | 192 cm |
Shipping (inner) case gross weight | 6.98 kg |
Package width | 104 mm |
Package depth | 161 mm |
Package height | 94 mm |
Package weight | 313 g |
Harmonized System (HS) code | 85176990 |
