Level One LevelOne NVR-0508 8-Kanal Netzwerk Videorek. PoE H.265/264

LEVEL ONE

NVR-0508

Jauns

NVR-0508 GEMINI 8-Ch PoE Network Video Recorder

Model Number
NVR-0508
SKU
53132003
  • Supports video resolutions up to 8 megapixels
  • Video compression: H.265, H.264, MPEG4
  • Built-in 8 PoE ports for PoE devices
  • Supports 4k2k HDMI local display
The LevelOne NVR-0508 NVR enables live view, recording and playback for up to 8 IP network cameras at the same time, featuring up to 8-megapixel resolution and H.265/H.264+/H.264/MPEG4 video compression. Operation is easy and intuitive via the web browser interface (IE), enabling remote monitoring and functionality. Mobile device operations are also supported (iOS/Android), with remote viewing via the LevelOne NVR app.. 2 HDD bays complete the package, with a disk capacity of up to 6TB making the LevelOne NVR-0508 a powerful, smart and cost-effective solution for managing your security network.An integrated 8-port 802.3at PoE switch enables the NVR to run both power and data on the one cable to power up connected PoE cameras.Central Management System (CMS) software is included for free, with no license fees. The CMS is capable of managing up to 256 NVRs, making it suitable for large scale surveillance applications.
Other
Approval and complianceCE/FCC,uL
Supported browsersInternet Explorer 9.0 or above
Operating humidity10% RH ~ 90% RH
Operating temperature-10°C ~ 55°C
System specifications
Embedded systemLunix
BandwidthIncoming bandwidth: 80 Mbps Outgoing bandwidth: 160 Mbps
IndicatorsPower
Alarm
H.D.D.
ResolutionRecording at up to 8MP resolution
Recording resolution:
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/CIF/QCIF
Capability:
2-ch @ 4K, or 8-ch @ 1080p
HDMI Video Output at up to 4K (3840 *2160) Resolution
Storage capacity2 SATA each Up to 6TB capacity for each disk
Number of video channel8
Video formatH.265/H.264/H.264+/MPEG4 video formats
Features
FeaturesPre-Recording / Post-Recording
Search Date / Time / Event
Export video by USB / Web browser / CMS
Liveview & Playback on Smart phone iOS, Android
Physical Specifications
Product weight (kg)3
Default
ColorBlack
EAN4015867202272
Model NumberNVR-0508
Package contentsNVR-0508
Power Codrd
Resource CD
Filter
Max. Channels8
Max. HDD Bay2
RAID supportedNo
Akeneo
Dimensions (W x D x H)315 x 52 x 385 mm
