| Connectivity technology | Wired | | Host interface | USB | | Interface | WLAN | | USB version | 2.0 | | Maximum data transfer rate | 600 Mbit/s | | Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | | Wi-Fi | Y | | Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) | | Frequency range | 2.4 - 5 GHz | | Top Wi-Fi standard | Wi-Fi 5 (802.11ac) | | Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) | | WLAN data transfer rates supported | 150,200,433 Mbit/s | | Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM | | Security algorithms | WEP, WPA, WPA-PSK, WPA2, WPA2-PSK | | Internal | Y | | Component for | Notebook | | Product colour | Black | | Antenna | Y | | Antenna design | External | | Plug and Play | Y | | LED indicators | Status | | Certification | FCC, CE, RoHS | | USB powered | Y | | Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows XP | | Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.13 High Sierra | | Operating temperature (T-T) | 0 - 40 °C | | Storage temperature (T-T) | -40 - 70 °C | | Operating relative humidity (H-H) | 10 - 90% | | Storage relative humidity (H-H) | 5 - 90% | | Sustainability certificates | RoHS | | Width | 57.8 mm | | Depth | 18 mm | | Height | 173.4 mm | | Package width | 207 mm | | Package depth | 148 mm | | Package height | 42 mm | | Package weight | 140 g | | Harmonized System (HS) code | 85176990 | | Gain | 5 dBi | | Antennas quantity | 1 |
|
