Next-Gen AXE11000 Enterprise Wireless for High-Density EnvironmentsHigh-Density Connectivity Capable of connecting up to 2,000+ clientsUltra-Fast AXE11000 WiFi 6 Speed Simultaneous 4804 Mbps on 6 GHz, 4804 Mbps on 5 GHz, and 1148 Mbps on 2.4 GHz for 10.8 GbpsCentralized Cloud Management Manage the whole network with cloud access or the Omada appSmart Antennas Professional Smart Antenna technology and intelligent algorithms10GE Wired Performance Boosts overall throughput with a 10 Gbps Ethernet port160 MHz Bandwidth Channel Double the data at peak transmission times on a single stream with HE160Omada Mesh Technology More flexible and convenient wireless deploymentPoE++ Support Supports Power over Ethernet (802.3bt) for convenient deploymentExperience the Peak of WiFi with Smart Antennas Improve performance, lower interference, and extend coverage for user-heavy scenarios through TP-Link Smart Antenna technology. Equipped with an ingenious 6 GHz/5 GHz/2.4 GHz antenna array, EAP690E HD automatically selects the optimal antennas to cover all terminal devices via intelligent algorithms, delivering lag-free and superb WiFi experiences.Reliable Business Networks with Intelligent Power Supply With the intelligent power supply feature of EAP690E HD, the PoE switch can act as a backup power source. Intelligent power supply automatically and smoothly powers EAP690E HD when the DC adapter is accidentally disconnected, delivering a reliable and safe business network experience.Seamless Integration into Omada SDN The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface. Experience total control at your fingertips.Auto Channel Selection and Power Adjustment to Optimize Overall Performance Provides powerful wireless performance that significantly reduces WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same networkEasy Deployment & Higher Performance by Omada Mesh Easy Pairing, Less Wiring With Mesh technology, Omada APs save you from redundant wires by wirelessly extending your WiFi signal farther and more flexibly to hard-to-wire areas.Boosted Network Security and EfficiencySecure Guest Network with up to 32 SSIDs Guest network access provides enhanced security to guests. Different SSIDs also enable flexible access management.Boost Business with Facebook WiFi and SMS Login Captive portal (including SMS, Facebook Wi-Fi, Voucher) and 802.1x authentication help maintain authorized guests to use the network. Boost your business with a customized marketing page.WPA3 for Worry-Free Open Public Networks With advanced enterprise security, WPA3 provides more data security for previously unsecured and open WiFi hotspots.Band Steering Automatically moves dual band devices onto the wider 5 GHz/6 GHz band for faster connections.Load Balance Ensures large numbers of users have smooth network experiences in high-density business networks.Airtime Fairness Increases average network throughput in heavily congested environments.
|
| 2.4 GHz | Y | | 5 GHz | Y | | 6 GHz | Y | | Maximum data transfer rate | 11000 Mbit/s | | Maximum data transfer rate (2.4 GHz) | 1148 Mbit/s | | Maximum data transfer rate (5 GHz) | 2402 Mbit/s | | Maximum data transfer rate (6 GHz) | 4804 Mbit/s | | Ethernet LAN data rates | 10000 Mbit/s | | Frequency band | 2.4 / 5 / 5 / 6 GHz | | Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | | Security algorithms | WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3, WPA3-Enterprise | | Ethernet LAN (RJ-45) ports | 1 | | DC-in jack | Y | | Power over Ethernet (PoE) | Y | | Output voltage | 12 V | | Output current | 4.5 A | | Placement | Pole, Wall | | Product colour | White | | Reset button | Y | | Certification | CE, FCC, RoHS, IC | | Antenna type | Internal | | Width | 280 mm | | Depth | 280 mm | | Height | 59.1 mm | | Number of products included | 1 pc(s) | | Operating relative humidity (H-H) | 10 - 90% | | Operating temperature (T-T) | 0 - 40 °C | | Storage temperature (T-T) | -40 - 70 °C | | Storage relative humidity (H-H) | 5 - 90% |
|
