Zyxel Switch XGS1010-12 MultiGig V2 10-Port Unmanaged

Manufacturer: ZYXEL

Reference XGS1010-12-ZZ0102F

Condition: New

More info

12-Port 10G SFP+ Unmanaged Multi-Gigabit Switch provides high performance and simplified controls
The Zyxel XGS1010-12 comes with two 10G SFP+ uplink ports, two 2.5G Multi-Gigabit ports, and eight Gigabit Ethernet ports with plug-and play design. It has been designed specifically for customers who require an affordable 10GbE network connectivity over a variety of mixed environments from the home to the office.

Maximums the flexibility for your network.
The XGS1010-12 features with 1G ports, 2.5G Multi-Gigabit ports, as well as 10G fiber ports. This port combination is capable of servicing a range of network devices such as gaming pc, NAS, workstation, or WiFi 6 AP.

Experience hyper-fast 2.5G networking!
Equipped with two 2.5G Multi-Gigabit ports, the switch gives your wired connection a boost, with speeds that are 2.5 times faster than standard Gigabit connections. It is the most ideal option to work with new motherboard for speedy file transfers, lag-free gaming, and high-res video streaming.

10G SFP+ Ultra Speed Uplink.
Provide two SFP+ ports compatible with 10GbE, which offers higher transmission speeds, instantly upgrade to a hybrid high-speed network environment at a cost-effective price.

QoS for Better Traffic Control.
The Zyxel XGS1010-12 comes with two high-priority and two medium p-priority ports, which provides enhanced download quality, all while giving you a better surﬁng, gaming, and streaming experience on other devices.

Easy to Use, No Setup Required.
Its easy plug-and-play design allows you to connect the XGS1010-12 to VoIP, media players, game consoles, set-top box, and any other web browsing devices to your home or studio network without any configuration.

Saving energy and space.
The fanless design ensures noiseless operation. Also, its built-in Energy Efficient Ethernet function automatically adjusts power consumption to dynamically reduce power usage during low link utilization. The wall-mount installation design provides more flexibility for wired home or office networks.

Switch type	Unmanaged
Quality of Service (QoS) support	Jā
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
2.5G Ethernet (copper) ports quantity	2
SFP+ module slots quantity	2
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Full duplex	Jā
Flow control support	Jā
Auto MDI/MDI-X	Jā
Ethernet LAN data rates	10,100,1000 Mbit/s
MAC address table	16000 entries
Switching capacity	66 Gbit/s
Forwarding rate	49 Mpps
Jumbo frames support	Jā
Jumbo frames	12000
Packet buffer memory	1.5 MB
Access Control List (ACL)	Jā
Rack mounting	Nē
Product colour	Grey
Reset button	Jā
LED indicators	Jā
Power source	AC/DC
Power supply included	Jā
AC input voltage	100 - 240 V
DC input voltage	12 V
Input current	1.5 A
Power consumption (max)	15.61 W
Power over Ethernet (PoE)	Nē
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%
Width	250 mm
Depth	104 mm
Height	24 mm
Weight	768 g
Package width	306 mm
Package depth	225 mm
Package height	64 mm
Package weight	1.22 kg
Harmonized System (HS) code	85176990
