LEVEL ONE

WAC-2010

New

The LevelOne WAC-2010 is a Gigabit WLAN controller designed for use in small to medium-sized networks in SMEs, schools, guesthouses, hotels, and apartments. Central management of up to 128 APs provides complete wireless security and service solutions for any small to medium-sized wireless network.

The WAC-2010 integrates a variety of features that allow the administrator to easily build the AP configuration. Including tag-based VLAN settings, AP firmware updates, as well as monitoring of the number and status of connected APs and users.

The WAC-2010 controller is also an Internet gateway with a robust firewall to protect against intruders, 1 WAN and 4 LAN ports at Gigabit speed enable fast and reliable data distribution in the network.

The LevelOne WAC-2010 also supports real-time control of signal strength and interference information. With the results, the WAC-2010 automatically regulates network utilization, output power, RF coverage, and channel distribution of APs to optimize wireless coverage, roaming of end devices, and throughput.


Product colourBlack
Enclosure materialMetal
LED indicatorsActivity, Link, Power
Control display unitNē
Internal memory256 MB
Flash memory16 MB
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Cabling technology10/100/1000Base-T(X)
Ethernet LAN (RJ-45) ports4
WAN connectionEthernet (RJ-45)
Quality of Service (QoS) supportJā
Input voltage100 - 240 V
Input frequency50/60 Hz
Width294 mm
Depth189 mm
Height44 mm
Weight1.4 kg
Package width325 mm
Package depth241 mm
Package height81 mm
Package weight2.08 kg
Package typeBox
Quick start guideJā
Cables includedAC
Operating temperature (T-T)-20 - 55 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 95%
Sustainability complianceJā
Sustainability certificatesCE, Federal Communications Commission (FCC), RoHS
Country of originChina
