Zyxel NWA110AX WiFi 6 Access Point 802.11ax PoE+ 3er Pack

ZYXEL

NWA110AX-EU0103F

New

True WiFi 6 The NWA110AX is truly the next generation of wireless (WiFi 6) AP for businesses looking for a most economical upgrade path to 11ax. Its built-in 2nd Generation WiFi 6 (Qualcomm 802.11ax 2.0) chipset allows the access point to take advantage of the full range of WiFi 6 technologies including uplink OFDMA and MU-MIMO which can’t be found in earlier releases of 802.11ax products.Built for Superior performance The NWA110AX boasts an impressive quad-core processor to provide consistently smooth delivery to wireless clients. The NWA110AX is also built with premium power amplifiers and 4G/5G interface filters to deliver superior quality of service that make it one of the best in its class.Simpler upgrade path The NWA110AX has been designed to be highly efficient in PoE budget, allowing for an easy upgrade path for those wishing to experience all that WiFi 6 has to offer without the need to upgrade existing PoE+ switchesManage it your way! As it comes with support for NebulaFlex, Zyxel’s scalable, cloud-based management system, the NWA110AX can be managed via NCC (Nebula control Center) or simply operate alone (controller less). You can choose the way that is best suited to your needs.

2.4 GHzY
5 GHzY
Maximum data transfer rate1775 Mbit/s
Maximum data transfer rate (2.4 GHz)575 Mbit/s
Maximum data transfer rate (5 GHz)1200 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
Channel bandwidth80 MHz
MIMOY
MIMO typeMulti User MIMO
Wi-Fi Multimedia (WMM)/(WME)Y
Fast roamingY
VLAN supportY
Wireless isolationY
Band steeringY
Transmitting power (CE)20/22 dBm
Transmitting power (FCC)23 dBm
Receiver sensitivity-101 dBm
Security algorithmsSNMP, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-Enterprise, WPA3
MAC address filteringY
Auto Wireless Distribution System (WDS)Y
Web-based managementY
Ethernet LAN (RJ-45) ports1
DC-in jackY
Power over Ethernet (PoE)Y
AC input voltage12 V
Input current1.5 A
PlacementWall
Product colourWhite
CertificationFCC 15C FCC 15E ETSI EN 300 328 EN 301 893 LP0002 FCC 15B EN 301 489-1 EN 301 489-17 EN55022 EN55024 EN61000-3-2/-3 EN60601-1-2 BSMI CNS13438 EN 60950-1 IEC 60950-1 BSMI CNS14336-1
Antenna typeInternal
Antenna gain level (max)6 dBi
Width180 mm
Depth180 mm
Height39 mm
Weight453 g
Number of products included3 pc(s)
AC adapter includedY
Mounting kitY
Operating relative humidity (H-H)10 - 95%
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-30 - 70 °C
Storage relative humidity (H-H)10 - 90%
Harmonized System (HS) code85176990
