| 2.4 GHz | Y |
| 5 GHz | N |
| Maximum data transfer rate | 100 Mbit/s |
| Wi-Fi data rate (max) | 300 Mbit/s |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Frequency band | 2.4 - 2.4835 GHz |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at |
| Number of users | 64 user(s) |
| Channels quantity | 13 channels |
| Modulation | 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, QPSK |
| Wi-Fi Multimedia (WMM)/(WME) | Y |
| Operating modes | Access Point (AP),Gateway,Repeater,WISP |
| Quality of Service (QoS) support | Y |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
| Service Set Identifier (SSID) features | SSID broadcast on/off |
| Number of SSID supported | 4 |
| Web-based management | Y |
| Firmware upgradeable | Y |
| Ethernet LAN (RJ-45) ports | 1 |
| WAN connection | Ethernet (RJ-45) |
| Power over Ethernet (PoE) | Y |
| AC input voltage | 12 V |
| Input current | 1 A |
| Placement | Pole |
| Product colour | White |
| International Protection (IP) code | IP65 |
| Reset button | Y |
| Country of origin | China |
| Certification | CE |
| Internal | N |
| Antennas quantity | 2 |
| Antenna gain level (max) | 5 dBi |
| Width | 87 mm |
| Depth | 257 mm |
| Height | 38 mm |
| Weight | 400 g |
| CD manual | Y |
| CD quick installation guide | Y |
| Package width | 106 mm |
| Package depth | 332 mm |
| Package height | 95 mm |
| Package weight | 700 g |
| Package type | Box |
| Cables included | LAN (RJ-45) |
| Mounting kit | Y |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -40 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 350 mm |
| Master (outer) case length | 495 mm |
| Master (outer) case height | 452 mm |
| Master (outer) case gross weight | 2.1 kg |
| Products per master (outer) case | 20 pc(s) |
