DisplayPort 1.2 to Quad HDMI MST/SST Hub with Video Wall Processor

Specifications:

• AV Interface: DisplayPort to HDMI
• Interface Standard: DP 1.2 / HDMI 1.4b
• Supported Bandwidth: 21Gbps
• Maximum Input Resolution: 3840x2160@60Hz 4:4:4 8bit
• Maximum Output Resolution: 3840x2160@30Hz
• HDCP Support: 1.4
• Supported Audio: Audio Pass Through
• Separate Audio Ports: -
• Special Features:
  • Supports both MST and SST modes
  • Output ports are grouped in computers OS: 1+2=Display1, 3+4=Display 2
  • Supports extended and duplicated desktop mode
  • Requires an Intel / AMD graphics card that supports 4 displays via an MST enable DisplayPort output



Connectors:

• Input: 1 x DisplayPort (Female)
• Output: 4 x HDMI Type A (Female)
• Power: 5.5/2.5mm DC Socket

Physical properties:

• Dimensions (approx.) WxDxH: 155x72x25mm (6.1x2.83x0.98in)
• Housing Material: Metal
• Net Weight: 0.41kg (0.9lb)
• Operating Temperature: 0°C - 45°C (32°F - 113°F)
• Storage Temperature: 0°C - 70°C (32°F - 158°F)
• Humidity: 40-50% RH (non-condensing)
• Power Requirements: 5VDC 2A
• Colour: Black

Miscellaneous:

• Packaging Type: Carton Box
• Packaging Dimensions: 220x160x50mm (8.66x6.3x1.97in)
• Gross Weight: 0.59kg (1.3lb)
• Warranty (Years): 2
• Certificated: CE, FCC, REACH & RoHS

Package content:

• 4K DisplayPort to 4 x HDMI Video Wall Processor
• Multi-Country Power Supply Unit (UK, US, EU & AUS)
• Lindy Manual

Purchasing information:

• No.: 38418
• EAN: 4002888384186
