Delock Adapter USB Type-C™ male > DVI female (DP Alt Mode) 4K 30 Hz

Reference 61213

Condition: New

More info

This adapter by Delock is suitable for the connection of a DVI monitor to a computer with USB-C™ interface and Displayport alternate mode support. Thus, the adapter can be connected to different laptops like MacBook, Chromebook and similar. In addition, the adapter can also be operated on a Thunderbolt™ 3 interface.

System requirements:
• Windows 7/7-64/8.1/8.1-64/10/10-64, Windows 10 Mobile, Chrome OS,
Linux ex Kernel 4.3 / Kernel 4.9, Mac ex OS 10.12
• PC or laptop with a free USB Type-C™ port and Displayport alternate mode or
• PC or laptop with a free Thunderbolt™ 3 port

Specification:
• Connectors:
1 x USB Type-C™ male >
1 x DVI 24+5 female with nuts
• Chipset: Realtek RTD2171U
• DVI-D (Single Link), VGA not wired
• Displayport 1.4 specification
• Resolution up to 2560 x 1600 @ 60 Hz / 3840 x 2160 @ 30 Hz /
4096 x 2160 @ 24 Hz (depending on the system and the connected hardware)
• Transfer of digital video signals
• Supports 3D displays
• Supports HDCP 1.4 and 2.2
• USB bus powered
• Plug & Play
• Gold-plated connectors
• 1 x ferrite core
• Cable length without connectors: ca. 20 cm
• Colour: black

Package content:
• USB-C™ to DVI adapter

Data sheet:
http://www.delock.de/produkt/61213/pdf.html?sprache=en
