CONCEPTRONIC ZEUS USV 2000VA 1800W Online UPS,IEC EPO Port

Conceptronic

ZEUS52E2K

New

Introducing the Conceptronic Online Tower UPS, the ultimate power backup solution for your home or office. With an ECO Mode for energy-saving operation and compatibility with generators, this UPS ensures continuous power even during extended outages. Equipped with HID USB communication, you can seamlessly connect and communicate with your devices for enhanced control and monitoring. For added safety during emergencies, the UPS is equipped with an Emergency Power Off (EPO) port, allowing for quick shutdown in critical situations. With its sleek tower design, the Conceptronic Online Tower UPS fits seamlessly into any environment, providing reliable power backup when you need it most.

UPS topologyDouble-conversion (Online)
Output power capacity2 kVA
Output power1800 W
WaveformSine
Input operation voltage (min)220 V
Input operation voltage (max)240 V
Input frequency50/60 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Maximum current10 A
Output power factor0.9
ECO mode
Emergency Power Off (EPO)
Input current Total Harmonic Distortion (THD)5%
Power protection featuresShort circuit
Audible alarm modesAlarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Country of originChina
AC outlet typesC13 coupler
AC outlets quantity6 AC outlet(s)
USB port
USB 2.0 ports quantity1
USB port typeUSB Type-B
Serial interface
Serial interface typeRS-232
RS-232 ports1
Battery capacity9 Ah
Battery voltage12 V
Battery recharge time4 h
Battery capacity108 Wh
Form factorTower
Product colourBlack
Cooling typeActive
Display typeLCD
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 90%
Compliance certificatesCE, RoHS
Width151 mm
Depth394 mm
Height225 mm
Weight17.1 kg
Cables includedInput power cable, RS-232, USB cable
Quick installation guide
Products per pallet30 pc(s)
Pallet gross length100 cm
Pallet gross width120 cm
Pallet gross height12.6 cm
Harmonized System (HS) code8504402000
Master (outer) case width241 mm
Master (outer) case length510 mm
Master (outer) case height313 mm
Master (outer) case gross weight17.6 kg
Products per master (outer) case1 pc(s)

UPS lineinteractive
