| UPS topology | Double-conversion (Online) |
| Output power capacity | 3 kVA |
| Output power | 2700 W |
| Waveform | Sine |
| Input operation voltage (min) | 220 V |
| Input operation voltage (max) | 240 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Maximum current | 16 A |
| Output power factor | 0.9 |
| ECO mode | Jā |
| Emergency Power Off (EPO) | Jā |
| Input current Total Harmonic Distortion (THD) | 5% |
| Power protection features | Short circuit |
| Audible alarm modes | Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm |
| Country of origin | China |
| AC outlet types | C13 coupler, C19 coupler |
| Power plug | C19 coupler |
| AC outlets quantity | 5 AC outlet(s) |
| USB port | Jā |
| USB 2.0 ports quantity | 1 |
| USB port type | USB Type-B |
| Serial interface | Jā |
| Serial interface type | RS-232 |
| RS-232 ports | 1 |
| Battery capacity | 9 Ah |
| Battery voltage | 12 V |
| Battery recharge time | 4 h |
| Battery capacity | 108 Wh |
| Form factor | Tower |
| Product colour | Black |
| Cooling type | Active |
| Display type | LCD |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Compliance certificates | CE, RoHS |
| Width | 196 mm |
| Depth | 416 mm |
| Height | 342 mm |
| Weight | 21.3 kg |
| Cables included | Input power cable, RS-232, USB cable |
| Quick installation guide | Jā |
| Products per pallet | 16 pc(s) |
| Pallet gross length | 100 cm |
| Pallet gross width | 120 cm |
| Pallet gross height | 12.6 cm |
| Harmonized System (HS) code | 8504402000 |
| Master (outer) case width | 295 mm |
| Master (outer) case length | 519 mm |
| Master (outer) case height | 458 mm |
| Master (outer) case gross weight | 22.3 kg |
| Products per master (outer) case | 1 pc(s) |
