LINDY Extender HDMI 2.0 18G Fibre Optic & IR 300m

Lindy

38174

New

Extends HDMI 2.0 18G signals up to 300m over a single duplex LC cable Supports resolutions up to  4K 60Hz Ultra HD, with High Dynamic Range Bi-directional IR or RS-232 for seamless, flexible control HDCP 2.2 support to ensure maximum compatibility 2 year warrantyThe Lindy 300m Fibre Optic HDMI & IR Extender is a high performance solution for extending  4K 60Hz Ultra HD transmissions over incredible distances, which are not possible with traditional copper based systems, using a single standard LC duplex multimode (50/125µm) fibre optic cable.Support for the HDMI 2.0 specification allows for the transmission of highly detailed 4K Ultra HD resolutions, using smart methods of compression, which decompresses the signal at the receiver for a visually lossless picture. Also providing support for High-Dynamic Range, video content can be seen with enhanced brightness, greater contrasts and a much wider colour gamut, perfect for creating eye-catching digital signage in retail, impressive residential installations or taking sports venue distribution to new immersive levels. HDCP 2.2 compatibility also means that protected 4K content including movies and TV shows can be viewed without issue.As opposed to the use of copper based extension systems, the use of fibre optic cable also ensures immunity to RF and EMI, providing a stable signal in ‘noisy’ retail or industrial environments which can have a high interference from electronics.With the ability to extend signals up to 300m the extender provides huge installation flexibility, the transmitter can be easily connected to a variety of HDMI source devices such as Blu-Ray players, 4K HDR media players or PC's in a convenient location, while the receiver can be placed in a suitable viewing area along with a 4K display or projector.The extender can also support 4K@30Hz non-HDCP content up to 1.5km with single mode fibre cable, great for even longer distance distribution of gaming or PC content. The included mounting brackets also allow for a neat installation under desks or discreetly hidden behind displays. In addition, the power supply is connected via a screw type DC jack, providing a more secure and reliable connection, perfect for professional installations where accidental disconnections could create a major issue.Featuring bi-directional IR and RS-232 ports, the extender provides the capability for source equipment to be seamlessly controlled from the display side, and the display can also be controlled from the HDMI source device, great for providing simple, flexible control over the installation for the user. Alternatively, when IR is not used, support for RS-232 enables the extension of control signals as part of a larger installation.

TypeAV transmitter & receiver
Maximum resolution3840 x 2160 pixels
Maximum transfer distance300 m
Maximum refresh rate60 Hz
Fiber optic wavelengths supported850 nm
Extended display identification data (EDID)Y
HDCP pass-throughY
Bandwidth18 Gbit/s
HDCPY
MaterialMetal
Product colourBlack
CertificationCE, FCC, REACH
Connectivity technologyWired
HDMI in1
Number of HDMI outputs1
HDMI version2.0
Fiber optic connectorLC
Digital audio optical in2
Serial interface typeRS-232
Remote (IR) input2
Remote (IR) output2
DC-in jackY
Operating voltage12 V
Input current0.5 A
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)10 - 90%
Width150 mm
Depth20 mm
Height74.4 mm
Weight300 g
Package width305 mm
Package depth180 mm
Package height75 mm
Package weight1.23 kg
AC adapter includedY
ManualY
IR blaster includedY
IR receiver includedY
Sustainability certificatesRoHS
