Mini DisplayPort to HDMI Converter

Specifications

• AV Interface: Mini DisplayPort to HDMI
• Interface Standard: DisplayPort 1.1, HDMI 1.4
• Supported Bandwidth: 4.45Gbps
• Maximum Input Resolution: 1920x1080@60Hz
• Maximum  Output Resolution: 1920x1080@60Hz
• Chipset: NXP PTN3361BBS
• HDCP Support: HDCP 1.4
• Supported Audio: Audio pass-through, if mDP port supports audio output
• Separate Audio Ports: -
• Special Features: Passive converter

Connectors

• Input: Mini DisplayPort (Male)
• Output: HDMI Type A (Female)

Physical properties

• Dimensions (approx.) WxDxH:
  • 18.7x10.8x9mm (0.74x0.43x0.35in)
  • 41.7x22x12mm (1.64x0.87x0.47in)
• Cable Length: 100mm (3.94in)
• Housing Material: ABS
• Jacket Material: PVC
• Jacket Diameter: 4.5mm (0.18in)
• Minimum Bend Radius: 45mm (1.77in)
• Net Weight: 0.017kg (0.04lb)
• Operating Temperature: 0° to 70° (32°F - 158°F)
• Storage Temperature: -10° to +80° (14°F - 176°F)
• Humidity: 10 - 85% RH (non-condensing)
• Colour: White

Miscellaneous

• Packaging Type: Polybag
• Packaging Dimensions: 176x194x20mm (6.93x7.64x0.79in)
• Gross Weight: 0.026kg (0.06lb)
• Warranty (Years): 2
• Certificated: CE, FCC, RoHS, REACH, Calif. Prop. 65

Package Contents

• Mini DisplayPort to HDMI Converter

Purchasing Information

• No.: 38309
• EAN: 4002888383097
