MANHATTAN Barcodescanner Kontakt CCD USB 60mm schwarz

MANHATTAN

178488

New

Improve speed, accuracy and productivity._x000D_ Manhattan CCD Contact Barcode Scanners deliver high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The CCD (charged-coupled device) scan engine features no moving parts for years of reliable service reading popular barcodes, including UPC, EAN, ASCII and GS1 DataBar. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application, where it appears as if it were manually typed or directly keyed into the computer. Its USB cable interface integrates with most PCs without an external power supply. With a scan rate of 100 scans per second and an accurate read range of up to 60 mm (2.4 in.), this model offers a practical daily scanning solution for point-of-sale, shipping, warehousing, office and industrial applications to minimize manual data entry, speed transactions and reduce errors.

TypeHandheld bar code reader
Scanner type1D
Sensor typeCCD
Linear (1D) barcodes supportedCodabar, Code 11, Code 128, Code 39, Code 93, JAN, MSI, U.P.C.
2D (matrix & stacked) barcodes supportedNot supported
Working distance6 cm
Read rate (max)100 reads/s
Light levels (direct sunlight)0 - 5000 lx
Wavelength632 nm
Maximum scan width6 cm
Scanner resolution0.127 mm
Connectivity technologyWired
Standard interfacesKeyboard wedge, RS-232, USB
Cable length1.524 m
Product colourBlack
Housing materialAcrylonitrile butadiene styrene (ABS)
Certification• FCC • CE • RoHS
Input voltage5 V
Power consumption80 mA
Weight180 g
Width80 mm
Depth180 mm
Height63.5 mm
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)20 - 95%
Sustainability certificatesRoHS
Harmonized System (HS) code84716070
