Delock USB Barcode scanner 1D with connection cable - Line scanner

DELOCK

90279

New

This wired USB barcode scanner by Delock can be connected to a free USB Type-A female port on a PC or laptop. With this linear barcode scanner laser class 1 and its linear CMOS image sensor, all common 1D barcode types can be accurately detected even at long distances. Furthermore, this handheld barcode scanner is able to read barcodes shown on displays and monitors. The scanner automatically adjusts itself to ambient brightness and captures up to 280 scans in a second under optimal light conditions. With low ambient light the barcode is illuminated by an additional white LED and can be used in low light conditions. Thanks to the used laser technology, the laser light is harmless to the human eye.
System requirements:
• Windows 7/7-64/8.1/8.1-64/10/10-64, Linux ex Kernel 4.4.x
• PC or laptop with a free USB Type-A port
Specification:
• Connector: 1 x USB Type-A male
• Resolution: 0.0762 mm
• Trigger: scan button
• Reading distance: ca. 25 mm to 507 mm
• Light source: laser class 1, 650 nm
• Light colour: visible laser red
• Compensation light: LED white
• Sensor: linear CMOS image sensor
• Scan rate: up to 280 scans per second
• Scan angle: 41°
• Surrounding brightness: max. 50000 Lux
• Input voltage: 5 V
• Current consumption:
  operation: max. 160 mA
  standby: max. 80 mA
• Operating temperature: 0 °C ~ 40 °C
• Storage temperature: -10 °C ~ 60 °C
• Relative humidity: 0 - 95 % (non condensing)
• Colour: black / grey
• Weight: ca. 170 g
• Dimensions (LxWxH): ca. 156 x 71 x 91 mm
• Cable length: ca. 2 m
• Scancodes:
  UPC-A / UPC-E
  EAN-8 / EAN-13
  Matrix 2 of 5
  China Postal Code (Toshiba Code)
  Industrial 2 of 5
  Interleaved 2 of 5
  Codabar
  Code 11
  Code 32
  Standard Code 39
  Full ASCII Code 39
  Code 93
  Code 128
  EAN / UCC 128
  MSI Plessey Code
  UK Plessey Code
  Telepen Code
  GS1 Databar
  IATA Code
Package content:
• Barcode scanner
• User manual
Data sheet:
http://www.delock.de/produkt/90279/pdf.html?sprache=en
