New

Intel WiFi Netzwerkadapter M.2 2230/M.2 1216 6 AX200

Manufacturer: Intel

Reference AX200.NGWG.NV

Condition: New

More info

Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.

Connectivity technology	Wireless
Host interface	PCI Express
Interface	WLAN
Maximum data transfer rate	2400 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w
Wi-Fi	Jā
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Security algorithms	64-bit WEP, 128-bit AES, 128-bit WEP, 256-bit AES, AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, TKIP, WPA2, WPA3, WPS
Bluetooth	Jā
Bluetooth version	5
Internal	Jā
Component for	PC/Laptop
Antenna type	2x2
Package size	22 x 30 x 2.4 mm
Compatible operating systems	Windows 10, 64-bit\|Linux
Windows operating systems supported	Windows 10 x64
Linux operating systems supported	Jā
Other operating systems supported	ChromeOS
Operating temperature (T-T)	0 - 80 °C
Width	22 mm
Depth	30 mm
Height	2.4 mm
Weight	2.83 g
Harmonized System (HS) code	85176990
Maximum operating temperature	80 °C
Supported Under vPro	Jā
Interface type	Wi-Fi(PCIe), BT(USB)
Product type	Wireless
Processor family	Intel Wi-Fi 6 Products
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G165483
Compliance	FIPS, FISMA
MU-MIMO	Jā
Launch date	Q2'19
Product brief URL	https://www.intel.com/content/dam/www/public/us/en/documents/product-briefs/wi-fi-6-ax200-module-brief.pdf
Status	Launched
Product series	Intel® Wireless Products
Product codename	Cyclone Peak
