Delock Module MiniPCIe I/O PCIe full size Graphics Adapter for VGA / DVI / HDMI -40 °C ~ 85 °C

Reference 95255

Condition: New

More info

This Mini PCIe adapter by Delock expands the PC by two monitor interfaces. VGA, DVI or HDMI monitors can be connected to these interfaces by using the optional cables. The adapter has an extended temperature range of -40 ° C ~ 85 ° C.

System requirements:
• Windows 7/7-64/8.1/8.1-6410/10-64, Linux Ubuntu-Fedora-RedHeat
• PC with one free Mini PCI Express slot
• Connection cable

Specification:
• Connector:
2 x 40 (40 DP) 1.25 mm pin header
1 x Mini PCI Express, Rev. 1.0
• Interface: PCI Express revision 1.0
• Formfaktor: Mini PCIe full size
• Chipset: SM750
• Resolution VGA up to 1920 x 1080 @ 75 Hz
• Resolution HDMI up to 1080p
• Resolution DVI-D up to 1080p - Single Link
• Supports simultaneous on two displays
• Power consumption: ca. 600 mA
• Operating temperature: -40 °C ~ 85 °C Industrial grade
• Storage temperature: -55 °C ~ 95 °C
• Vibration: 5 G @ 7 ~ 2000 Hz
• Schock: 50 G @ 0.5 ms

Package content:
• Graphics adapter

Data sheet:
http://www.delock.de/produkt/95255/pdf.html?sprache=en
